VOR NAVIGATION (IC-A24E ONLY)
■ VOR indicators
COM BAND
(118.000 136.975 MHz)
Course indicator
To-from flag indicator
Two-degree deviation
marks
Course deviation
needle
18
NAV BAND (108.000 117.975 MHz)
Course indicator
Push [F], then push [1
CDI MODE
General VOR equipment
214
FROM
Course
indicator
34
DVOR MODE
].
Push [F], then push [4
DVOR
Function display of the IC-A24E
Course deviation needles
Overflow indicator
To-from flag
indicator
].
CDI
To-from flag indicator
