PROGRAMMABLE FEATURES,
SETUP & OPERATION
3 Press the ZONE button until the name of the zone you wish to
program appears on the upper left screen. Selecting "ALL
ZONES" allows you to create one schedule for the entire home.
4 If the text "ALLDAYS" appears at the top of the screen, you are
ready to start.
Press either the LEFT or RIGHT button repeatedly as necessary
until "ALLDAYS" is displayed. The WAKE time period will be high-
lighted.
5 Using the TIME (+\-) button, set the start time for this time
period.
6 Press the red HEAT button. Heating temperature will begin
flashing.
7 Set the heating temperature using the TEMP (+\-) button.
8 Press the blue COOL button. Cooling temperature will begin
flashing.
9 Set the cooling temperature using the TEMP (+\-) button.
10 Use the SCROLL button to highlight the next period, then
repeat steps 5 – 9 to select settings for DAY, EVENING and
SLEEP.
11 Exit the scheduling mode by either closing the door or pressing
the SCHEDULE button.
12 To create a custom schedule for the remaining zones, press the
ZONE button to select the next zone you wish to program.
Then, repeat steps 4 - 10 in this section.
- OR -
- OR -
19
