PRODUCT OVERVIEW

Documentation

The following documentation is available on the Multi-Tech Installation Resources website at
www.multitech.com/setup/product.go.
Document
MultiConnect Cell User
Guide
EV-DO EV3 and CDMA C2 AT You can configure the MTC-C2 device using the CDMA C2 AT Commands. These
Commands Reference Guide commands are documented in the Reference Guide part number S000546.

Descriptions of LEDs

Devices that have a serial connector have the following LEDs:
■
Power
■
TR
■
CD
■
LS
Devices that have a USB connector have the following LEDs:
■ Power
■ LS
The tables that follow provide details about what the LEDs indicate.
Power
Not lit DC power not present.
Lit DC power present.
TR (Terminal Ready)
Not Lit Data is not being transmitted.
Lit Blinks when data is being transmitted.
CD (Carrier Detect)
Not lit Data connection is not established.
Lit Data connection is established.
LS (Link Status)
Not lit There is no power to the cellular radio.
Continuously Powered and connected, but not transmitting or receiving.
lit
Slow blink Powered and searching for a connection.
Fast blink Transmitting or receiving.
6
Description
This document. Provides an overview, safety and regulatory information,
schematics, and general device information.
®
MultiConnect Cell User Guide
