CELLULAR INFORMATION
Cellular Information
Antenna
The antenna intended for use with this unit meets the requirements for mobile operating configurations and for
fixed mounted operations, as defined in 2.1091 and 1.1307 of the FCC rules for satisfying RF exposure compliance.
If an alternate antenna is used, consult user documentation for required antenna specifications.
CDMA Antenna Information
CDMA devices were approved with the following antenna:
Exceltek Electronics, Ltd.
Description: Quad band antenna
Part number: C0081-ANG0002
Multi-Tech part number: 45009713L
CDMA Antenna Requirements/Specifications
Frequency range
Impedance
VSWR
Typical antenna gain
Radiation pattern
Polarization
12
824-894 MHz / 1850-1900 MHz
50 ohm
Make sure VSWR does not exceed 2.0.1 at any point
across the bands of operation
2 dBi on azimuth plane
Omni directional
Vertical
®
MultiConnect
Cell User Guide
