- Page 1 3G SDI Splitter/Switch 4 Input – 2 Output ID# 696 Operation Manual...
- Page 2 Introduction The 3G-SDI 4 by 2 Switcher/Splitter allows SD-SDI, HD-SDI and 3G- SDI signals to be switched from up to four SDI sources and split to two SDI outputs while ensuring high bit rates of 2.970 Gbit/s to give you high bandwidth signal transmission without signal loss over long distances and can be controlled via IR or RS-232.
-
Page 3: Sdi Output
Operation Controls and Functions Front panel Power LED The LED will illuminate green when the device is connected to a power supply. IR receiver IR receiver window receives IR commands from the supplied remote control. SDI Input select/Indicator LEDs 1~4 Press the input button repeatedly to cycle through the SDI input sources, the red LED will illuminate to indicate which input source is currently selected. - Page 4 RS-232 Protocols Pin Assignment Pins definition of modem cable 3G-SDI 4 by 4 Switcher/Splitter Remote Controller Definition Definition Baud Rate: 19200 bps Data bit: 8-bits Parity: None Stop bit: 1-bit Flow Control: None Commands Command Action poweroff Power OFF poweron Power ON input01 Input selection 1...
- Page 5 Remote Control 1. Power Press the button to turn the unit ON or to standby mode. 2. Direct Input Selector Press 1, 2, 3 or 4 to select the required input source. When the device is in 'Standby', press any button to turn the device on. Installation...
- Page 6 Specifications SMPTE Standard 425M Level A & B, 424M, 292M, 259M-C SDI Transmission Rates 2.970 Gbit/s and 2.970/1.001 Gbit/s Input 4×BNC (SD/HD/3G-SDI) Output 2×BNC (SD/HD/3G-SDI) SDI Timing Support SD-SDI: SMPTE 259M-C, 270 Mbit/s HD-SDI: SMPTE 292M, 1.485 & 1.485/1.001 Gbit/s 3G-SDI: SMPTE 424M/425M-AB, 2.970 &...
