PRODUCT OVERVIEW
Category Description
SMS
SMS
Connectors
Cellular Female SMA connectors for cellular
WiFi Reverse polarity male SMA connector for Wi-Fi
SIM Holder Standard 1.8 and 3 V SIM receptacle
GPS Female SMA connector
Power Requirements
Voltage 7 V to 32 V DC
Physical Description
Dimensions Dimensions are shown in the section "Dimensions" that follows.
Weight 8.2 ounces or 230 grams
Environment
Operating -40° C to +85° C
Temperature
Humidity Relative humidity 15% to 93% non-condensing
Certifications, Compliance, Warranty
EMC
Compliance
Safety
Compliance
Network GCF
Compliance
Warranty Two years
*UL Listed @ 40° C, limited by power supply. UL Certification does not apply or extend to an ambient above 40° C
and has not been evaluated by UL for ambient greater than 40° C.
UL has evaluated this device for use in ordinary locations only. Installation in a vehicle or other outdoor locations
has not been evaluated by UL. UL Certification does not apply or extend to use in vehicles or outdoor applications
or in ambient above 40° C.
Note: The radio's performance may be affected at the temperature extremes. This is considered normal. There is
no single cause for this function. Rather, it is the result of an interaction of several factors, such as the ambient
temperature, the operating mode and the transmit power.
8
Point-to-Point Messaging
Mobile-Terminated SMS
Mobile-Originated SMS
EN55022 Class B
EN55024
UL 60950-1
IEC 60950-1
®
