TABLE OF CONTENTS

IMPORTANT ...................................... i
SYSTEM REQUIREMENTS .............. i
OPERATING THEORY ....................... i
OPERATING NOTES ......................... i
CAUTIONS ........................................ ii
TABLE OF CONTENTS .................... iii
1 INSTALLATION ...................... 1 - 5
Hardware installation ................ 1
Antenna installation .................. 2
Grounding ................................. 2
AF output level selection ........... 3
Software installation ................. 4
RS-232C port setting ................ 5
Mouse property setting ............. 5
2 PANEL DESCRIPTION ........ 6 - 15
Multi-function receiver screen ... 6
Function display ...................... 10
Simple function receiver
screen ..................................... 12
Function controller screen ...... 14
Simple function receiver sub
screens ................................... 15
iii
3 BASIC OPERATION ........... 16 - 21
Receiving ................................ 16
Setting a frequency ................. 17
Setting a tuning step ............... 18
Receive mode selection ......... 18
Automatic mode selection ...... 19
Setting squelch level ............... 20
IF filter selection ..................... 20
Attenuator function ................. 21
Automatic noise limiter ........... 21
4 MEMORY CHANNELS ....... 22 - 25
General ................................... 22
Saving memory channels ........ 22
Selecting a memory channel ... 23
Memory channel
programming .......................... 24
Clearing a memory channel .... 24
Editing the memory list ........... 25
5 SCAN OPERATION ............ 26 - 33
Scan types .............................. 26
Programmed scan .................. 27
Setting scan edges ................. 28
Auto memory write scan ......... 29
Memory scan .......................... 30
Versatile memory scan ........... 31
Scan resume condition ........... 32
Scan speed setting .................. 33
6 BAND SCOPE .................... 34 - 35
Operation ................................ 34
Changing the automatic
sweep step limit ...................... 35
7 TONE SQUELCH OPERATION ... 36
8 TROUBLESHOOTING .............. 37
9 SPECIFICATIONS AND SUPPLIED
ACCESSORIES .................... 38 - 39
Specifications ......................... 38
Supplied accessories .............. 39
