SPECIFICATIONS AND OPTIONS

I Specifications
D D GENERAL
• Frequency coverage
USA
Australia, Asia
Korea
Taiwan
* 1 Guaranteed: 144–148 MHz range only.; *
430–440 MHz for the General version; *
ranges are inhibited for USA version and not guaranteed.
• Type of emission
• Number of memory channels
• Frequency resolution
• Operating temperature range
• Frequency stability
• Power supply requirement
• Current drain
(at 13.8 V DC: approx.)
Transmit
Receive
• Antenna connector
• Dimensions
(proj. not included)
• Weight
(approx.)
77
:
Rx 118.000–173.995 MHz* 1 ,
230.000–549.995 MHz* 2 ,
810.000–999.990 MHz* 3
Tx 144–148 MHz, 440–450 MHz
Rx 118.000–173.995 MHz* 1 ,
230.000–549.995 MHz* 2 ,
810.000–999.990 MHz
Tx 144–148 MHz, 430–440 MHz
Tx/Rx 144–146 MHz, 430–440 MHz
Tx/Rx 144–146 MHz, 430–432 MHz
2 Guaranteed: 440–450 MHz range for the USA,
3 824.005 to 848.995 and 869.005 to 893.995 MHz
: FM, AM
(Receive only)
: 512 (incl. 10 scan edges and 2 calls)
: 5, 10, 12.5, 15, 20, 25, 30, 50, 100,
200 kHz
: –10°C to +60°C; +14˚F to +140˚F
: ±10 ppm
(–10°C to +60°C)
: 13.8 V DC ±15%
:
at 55 W 12 A
standby 0.8 A
max. audio 1.0 A
(50 Ω)
: SO-239
: 141(W) × 40(H) × 185.4(D) mm
5 ⁄ (W)×1 ⁄ (H)×7 ⁄ (D) in
9 9 5
16 16 16
: 1.2 kg; 2 lb 10 oz
D D TRANSMITTER
• Modulation system : Variable reactance frequency modulation
• Output power : VHF
• Max. frequency deviation : ±5.0 kHz
• Spurious emissions : Less than –60 dB
• Microphone connector : 8-pin modular
D D RECEIVER
• Receive system : Double-conversion superheterodyne
• Intermediate frequencies : 1st: 46.05 MHz, 2nd: 450 kHz
• Sensitivity
(FM: at 12 dB SINAD/AM: at 10 dB S/N)
118.000–173.995 MHz
230.000–299.995 MHz
300.000–499.995 MHz
500.000–549.995 MHz
810.000–999.990 MHz
• Squelch sensitivity † : Less than 0.13 µV
(threshold)
• Selectivity :
Wide
Narrow
• Spurious and image rejection : More than 60 dB
• AF output power : More than 2.0 W
(at 13.8 V DC)
• Ext. speaker connectors : 3-conductor 3.5 (d) mm (
All stated specifications are subject to change without notice or obligation.
55/15/5 W*
(approx.)
UHF 50/15/5 W*
(approx.)
*50/15/2 W for Korean version and 25/15/5 W
only for the Taiwan version.
(wide)
±2.5 kHz
(narrow: approx.)
(600 Ω)
:
0.18 µV/0.45 µV
0.32 µV/0.79 µV
0.22 µV/0.63 µV
0.32 µV/Not specified
0.45 µV/Not specified
More than 12 kHz/6 dB
Less than 30 kHz/60 dB
More than 6 kHz/6 dB
Less than 20 kHz/60 dB
at 10% distortion with an
8 Ω load
")/8 Ω
