32 | Getting Started

Figure 10: Lock SD Card Door

Installing the Battery

There are two sizes of batteries available for the TC55; a 2,940 mAh battery and a 4,410 mAh battery.
Procedure:
1 Align the three tabs on the bottom of the battery with the three slots in the battery compartment.
2 Press the battery down and then rotate until it locks into place.

Figure 11: Inserting the 2,940 mAh Battery

September 2013 | MN000015A01
