TC55
QUICK START GUIDE

Advertisement

Table of Contents
loading

Related Manuals for Motorola TC55

Summary of Contents for Motorola TC55

  • Page 1 TC55 QUICK START GUIDE...
  • Page 2 Battery Cover Notch Exit Window USB Connector (Optional) Power Button Microphone Flash Headset Jack Unpacking The following items are in the box: • TC55 • Lithium-ion battery (2,940 or 4,410 mAh) • Charging Cable • Quick Start Guide • Regulatory Guide.

  • Page 3: Installing The Sim Card

    Installing the SIM Card NOTE The TC55 accepts full size SIM cards. If using micro or nano SIM cards, a third-party adapter is required. CAUTION For proper electrostatic discharge (ESD) precautions to avoid damaging the SIM card. Proper ESD precautions include, but not limited to, working on an ESD mat and ensuring that the user is properly grounded.

  • Page 4: Installing An Optional Microsd Card

    Note the position of the card notch. Insert the microSD card into the card holder. Close the SD card door. Slide the SD card door toward the bottom of the TC55 to lock into place.

  • Page 5: Installing The Battery

    Installing the Battery Align the three tabs on the bottom of the battery with the three slots in the battery compartment. Press the battery down and then rotate until it locks into place. 4,410 mAh 2,940 mAh Align the battery door with the back of the device and press the battery door down until it snaps into place.
  • Page 6 4.5 hours. Description Slow Flashing Green TC55 is charging. Solid Green TC55 is fully charged. Fast Flashing Red Charging error. Not charging. Turning On the TC55 Press the Power button for at least one second to turn on the TC55.

  • Page 7: Replacing The 2,940 Mah Battery

    Replacing the 2,940 mAh Battery To replace the 2,940 mAh battery: Press the Power button until the menu displays. Touch Power off. Touch OK. Place thumbnail at battery cover notch and lift the battery cover. Pull the battery tab down at a 45° angle. Remove the battery out of the battery compartment.
  • Page 8 Align the battery door with the back of the device and press the battery door down until it snaps into place. Ensure that the battery door is seated properly and that no gaps are present. Press the Power button to turn on the TC55.

  • Page 9: Replacing The 4,410 Mah Battery

    Replacing the 4,410 mAh Battery To replace the 4,410 mAh battery: Press the Power button until the menu displays. Touch Power off. Touch OK. Place thumbnail at battery cover notch and lift the battery cover. With two fingers, press the battery down. Rotate the battery out of the compartment.
  • Page 10 Align the battery door with the back of the device and press the battery door down until it snaps into place. Ensure that the battery door is seated properly and that no gaps are present. Press the Power button to turn on the TC55.

  • Page 11: Data Capture

    LED lights red to indicate that data capture is in process. Programmable Button Move the TC55 until the bar code is centered under the red target. The LED lights green and a beep sounds, by default, to indicate the bar code was decoded successfully.

  • Page 12: Get More Information
