  • Page 1 8” Laser sLiding Compound mitre saw sF210JsL...
  • Page 3 Congratulations on your purchase of a power tool from Titan Power Tools (UK) Ltd. We want you to continue getting the best performance from it so this handbook includes information on safety, handling and care. Please retain this handbook in case you need to refer to any of the information in the future.

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS WARNING! To ensure safe operation when using your Sliding Mitre Saw with Laser, make sure you follow basic safety principles to reduce risk of personal injury, electric shock and fire. Please read the following instructions prior to operating this product and keep for future use. SAVE THESE INSTRUCTIONS Safety instructions Keep the work area clean.
  • Page 5 Never stare directly into the laser beam and never point the beam at anybody. The laser beam energy is extremely harmful to your eyes. Remove the mains plug from the socket before carrying out any adjustment or servicing. 8” Laser sLiding Compound mitre saw sF210JsL...
  • Page 6 AddITIONAl SAFETY INSTRUCTIONS FOR YOUR SlIdING MITRE SAw wITh lASER. Only wood or products such as medium density fibre board can be cut with this saw. Other materials may shatter or cause the blade to grab. 2. Never fit substandard blades to the saw. Only fit correctly sized saw blade. 3.
  • Page 7 5. Do not change the laser device with a different type. Repairs must be carried out by the manufacturer or an authorised agent. 8” Laser sLiding Compound mitre saw sF210JsL...
  • Page 8 VIBRATION The European Physical Agents (Vibration) Directive has been brought in to help reduce hand arm vibration syndrome injuries to power tool users. The directive requires power tool manufacturers and suppliers to provide indicative vibration test results to enable users to make informed decisions as to the period of time a power tool can be used safely on a daily basis and the choice of tool.
  • Page 9 SYMBOlS Read the manual Warning Wear gloves Wear dust mask Wear ear protection Wear eye protection 8” Laser sLiding Compound mitre saw sF210JsL...
  • Page 11 22. TAbLE ExTENSION ROD CLAMP SCREW 23. STRAIGHT GUIDE 24. VERTICAL CLAMP LOCKING SCREW 25. VERTICAL CLAMP 26. HEAD TILT CLAMPING KNOb 27. bATTERY STORAGE 28. DUST bAG 29. LASER GENERATOR 30. bLADE LOCK LEVER 31. TRANSPORTATION HANDLE 8” Laser sLiding Compound mitre saw sF210JsL...

  • Page 12: Technical Data

    TEChNICAl dATA Voltage: 230V~50Hz Input power: 1800W No load speed: 4600min Table turning range: 0º - 45º (Left) 0º - 45º (Right) Saw body tilting range: 0º - 45º Table support area: 420 X 220mm Laser wave length: =650nm Double insulation: Machine weight: 13.3kg Cutting capacity:...
  • Page 13 Hex spanner Dust bag Table extention rails Clamp vice Spare set carbon brushes bolts to fix base Note: battery for laser is not included in this item and AAA battery is reco- mended. 8” Laser sLiding Compound mitre saw sF210JsL...
  • Page 14 WARNING! before using your sliding mitre sure read instruction manual carefully. ASSEMBlY Assembly Rotary table lock handle Turn clockwise to tighten To install the rotary table lock handle, place the threaded stud on the end of the rotary table lock Fig 1 handle into the threaded hole in the control arm under work table.
  • Page 15 OPERATION INSTRUCTIONS 4xMounting hole WARNING: Use clamping position that Bolt does not interfere with operation. before switching on, lower saw head to make sure clamp clears guard and saw head assembly. Washer Fig 7 8” Laser sLiding Compound mitre saw sF210JsL...
  • Page 16 Note: • If you see some sparks flashing in the ventilation slots, do not panic this is normal and will not damage the machine. • Be certain the sliding mitre saw is mounted or placed on a level, firm work surface before using. A level and firm work surface can reduce the risk of the sliding mitre saw becoming unstable.
  • Page 17 1.Loosen the table lock handle by screwing it anticlockwise. 2.Move the saw to the desired angle by pressing the index lock lever and pushing the table lock handle so that the table turns. Set at the desired Fig 15 8” Laser sLiding Compound mitre saw sF210JsL...
  • Page 18 angle, and screw the lock handle clockwise and make sure it is fully tightened before cutting. 6. bEVEL CUT USING THE HEAD TILT (Fig16) A bevel cut is made at 0 mitre and any bevel angle in the range of 0O to 45 .
  • Page 19 On position, the laser generator then projects a visible red line on the workpiece surface, make your cut along the red line. 3. Switch off the laser after cutting. 8” Laser sLiding Compound mitre saw sF210JsL...
  • Page 20 Note: The saw dust may “lock” the laser beam, clean the laser generator periodically. WARNING: Never stare directly into the laser beam and never point the beam at anybody. 11. ADjUSTING THE LASER CUTTING GUIDE The laser generator has been factory calibrated. It requires re-calibration only when the laser beam deviates from the cut line.
  • Page 21 Then loosen and remove the blade securing bolt, and outer flange with the socket wrench provided. See Fig28, 29& Fig 28 Loosen slightly Fig 29 8” Laser sLiding Compound mitre saw sF210JsL...
  • Page 22 Note: Blade securing bolt has a left hand thread. Remove the blade, Fig31 (we recommend the use of a stout glove for this). Clean any saw dust and debris from the arbor and saw blade securing flanges. To refit the blade follow the above procedure in reverse order.

  • Page 23: Environmental Protection

    L. A 13AMP (BS1363 or BS1363/A) plug must be used and a 13 AMP fuse must be fitted. 13 AMP FUSE BLUE N (NEUTRAL) BROWN L (LIVE) OUTER SLEEVE CABLE GRIP 8” Laser sLiding Compound mitre saw sF210JsL...

  • Page 24: Declaration Of Conformity

    Declaration of Conformity We, Importer Titan Power Tools (UK) Ltd bA22 8RT Declare that the product SF210jSL MITRE SAW Complies with the essential health and safety requirements of the following directive: 2004/108/EC EMC Directive. 2006/95/EC Low Voltage Directive. 98/37/EC until December 28th 2009 and then with 2006/42/EC from 29th December 2009 Machinery Directive.
  • Page 25 8” Laser sLiding Compound mitre saw sF210JsL...
  • Page 27 8” Laser sLiding Compound mitre saw sF210JsL...
