Parallel Port

This port is usually connected to a printer. SAGP-845EV includes an on-board
parallel port accessed through a 26-pin flat-cable. Three modes― SPP, EPP and
ECP― are supported.
• LPT1: Parallel Port Connector
PIN Description
1 STROBE#
3 DATA 1
5 DATA 3
7 DATA 5
9 DATA 7
11 BUSY
13 PRINTER SELECT
15 ERROR#
17 PRINTER SELECT LN#
19 GROUND
21 GROUND
23 GROUND
25 GROUND
PIN Description
2 DATA 0
4 DATA 2
6 DATA 4
8 DATA 6
10 ACKNOWLEDGE
12 PAPER EMPTY
14 AUTO FORM FEED #
16 INITIALIZE
18 GROUND
20 GROUND
22 GROUND
24 GROUND
26 NC
12
1 14
13 26
