Chapter 3 Connection

This chapter describes how to connect peripherals, switches and indicators to the
SAGP-845EV board.
Table of Connectors
Label
FDD1 Floppy Disk Drive Connector
IDE1 Primary IDE Connector
IDE2 Secondary IDE Connector
LPT1 Parallel Port Connector
COM1, COM2 Serial Port Connectors
KBM1 PS/2 MOUSE & KEYBOARD Connector
USB1~USB3 USB Connectors
IR1 IrDA connector
FAN1~FAN3 Fan Connectors
LAN1 LAN RJ45 Connectors
CN3 LAN Status LED Connectors
VGA1 VGA 15-pin Female Connector
CN4 AUDIO Connector
CFA1 Compact Flash Socket
CN2 External Switches and Indicators
PW1 ATX BUTTON (Power ON) Switch
PW2 ATX-12V CPU Power Source
S1 CPU voltage setting
Function
