Summary of Contents for Atlona AT-PROHD85M-SR
- Page 1 User Manual 8 X 5 HDMI MATRIX SWITCH WITH 5 X CAT5 RECEIVERS INCLUDED AT-PROHD85M-SR Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515...
-
Page 2: Table Of Contents
9. RS-232 ..........10 9.1. RS232 Control ..........10 9.2. RS232 Cable Wiring ..........11 9.3. RS232 Commands ..........11 10. Safety Information ..........13 11. Warranty ..........14 12. Atlona Product Registration ..........15 Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515... -
Page 3: Introduction
INTRODUCTION The Atlona AT-PROHD85M-SR is an HDMI 8X5 matrix switch which allows up to eight HDMI sources to be independently switched to five HDMI displays. It extends sources such as Blu-Ray, X-Box or a Satellite receiver up to 165ft @ 1080p and 1920x1200 resolutions to each remote video display. It offers full pass through for all Digital audio formats such as Dolby True HD, DTS-HD Master Audio. -
Page 4: Specification
2. IR window: IR Receiver for supplied handheld remote. 3. Output selection buttons: used to select preferred output channel. 4. Input selection buttons: used to select preferred input channel. 5. F/N button: used to execute a command. 6. Power: On/off switch Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515... -
Page 5: Rear Panel
Note: Please make sure when connecting Cat5e-1 and -2 receiver ports that they are matched to the corre- sponding RJ45 Ports on the AT-PROHD85M-SR. Receiver Cat5e-1 should be plugged into Matrix RJ45-1 and Receiver Cat5e-2 should be plugged into Matrix RJ45-2. -
Page 6: Connection And Operation
2xCAT5e cable 2xCAT5e cable 1. Connect HDMI sources such as Blu-Ray, DirecTV or Apply TV to the inputs on the AT-PROHD85M-SR. 2. Connect 2 RJ45 CAT5 cables from each output on the AT-PROHD85-SR to the matching numbered inputs on the supplied receivers. It is important that that each end of the CAT5 cable matches the correspond- ing numbered RJ45/CAT5 port on the matrix &... - Page 7 AT-PROHD85M-SR before proceeding with any EDID configuration. A). Auto EDID: Please set the dip switch to “0000” (off). Power cycle the AT-PROHD85M-SR by turning power off then back on. All connected output displays EDID’s will be copied and forwarded to all connected sources and the lowest common denominator will be locked in.
- Page 8 Single CAT5, 1080i, 2ch audio C). Copy EDID: Please set the dip switch to “0000” (off). Make sure to power cycle the AT-PROHD85M-SR after making this setting change on the dip switch. Turn off power and then back on to complete a power cycle This function is used when you want a specific output and input to become associated.
-
Page 9: Ir Remote Control
(View RS232 codes on page 12) 7. For computer control connect a RJ45 cable to the TCP/IP port of the AT-PROHD85M-SR. Note: If the TCP/IP port is connected directly to a computer you must use a crossover CAT5 cable. If connect¬ed to a router use a straight wire CAT5 cable. -
Page 10: Tcp/Ip Control
2. Double Click on the device name or right-click and select OPEN. A web browser window will open with the log-in page. The default password is “0000000000”. Enter the password then select the “Login” button to log on to the control page. Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515... -
Page 11: Rs232
Next select “Search” and then “Read De- vice” to display the matrix name. RS232 9.1. RS232 Control Baud Rate: 9600 bps Data bits: 8 bits Parity: None Stop bits: 1 bit Flow control: None Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515... -
Page 12: Rs232 Cable Wiring
9.2. RS232 Cable Wiring AT-PROHD85M-SR Remote control device Definition Definition 9.3. RS232 Commands: Note: ‘ ’ is carriage return. OUTPUT COMMAND ACTION cir 00 Output 1 select Input1 cir 01 Output 1 select Input2 cir 02 Output 1 select Input3... - Page 13 Output 5 select Input3 cir 43 Output 5 select Input4 Output 5 cir 44 Output 5 select Input5 cir 45 Output 5 select Input6 cir 46 Output 5 select Input7 cir 47 Output 5 select Input8 Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515...
-
Page 14: Safety Information
It may also cause damage to your AT-PROHD85M-SR. Opening the product will void the warranty. Do not attempt to service the unit. Disconnect the product and contact your authorized Atlona reseller or contact Atlona directly. -
Page 15: Warranty
Atlona Technologies’ decision, either return of the price paid for the product, repair, or replacement of the product that does not meet this Limited Warranty and which is returned to Atlona Technologies with a copy of the Customer’s receipt. This Limited Warranty is void if failure of the product has resulted from accident, abuse, misapplication, or natural occurrence. -
Page 16: Atlona Product Registration
ATLONA PRODUCT REGISTRATION Thank you for purchasing this Atlona product. - We hope you enjoy it and will take an extra few moments to register your new purchase. Registration creates an ownership record if your product is lost or stolen and helps ensure you’ll receive notification of performance issues and firmware updates.
