i CHANNEL 16/CALL CHANNEL KEY [16/C]
Push to select Channel 16. (p. 9)
➥
Hold down for 1 second to select the Call channel. (p. 9)
➥
• "CALL" appears when the Call channel is selected.
Hold down for 3 seconds to enter Call channel program-
➥
ming mode when the Call channel is selected. (p. 12)
o SOFTKEYS
The desired functions as described below can be assigned
in the Menu screen.
Scan [ ] (p. 17)
Push to start or stop a Normal or Priority scan.
Dualwatch/Tri-watch [
Push to start a Dualwatch or Tri-watch.
➥
Push to stop a Dualwatch or Tri-watch when either is
➥
activated.
High/Low [ ] (p. 11)
Push to set the power to high or low.
• Some channels are set to only low power.
Channel [ ] (p. 9)
Push to select a regular channel.
AquaQuake [ ] (p. 15)
While holding down, the AquaQuake function is activated
to clear water away from the speaker grill.
] (p. 18)
PANEL DESCRIPTION
Favorite channel [ ] (p. 17)
Push to set or clear the displayed channel as a Favorite
➥
(Tag) channel.
Hold down for 3 seconds to clear or set all Favorite
➥
channels in the selected channel group.
Name [ ] (p. 12)
Push to enter the channel name programming mode.
Backlight [ ] (p. 15)
Push to enter the LCD and key backlight brightness ad-
justment mode.
• While in the adjustment mode, push [∫]/[√]/[Ω]/[≈] or rotate Dial
to adjust the brightness of the LCD and key backlight.
Log [ ] (p. 58)
Push to enter "RCVD CALL LOG" in the DSC CALLS menu.
