!3 KEY ICON (p. 6)
Shows the programmed function of the softkeys on the
front panel.
!4 TIME ZONE INDICATOR
Shows the current time when a GPS receiver is con-
➥
nected, or the time is manually programmed.
• When the GPS current time is invalid, "??" will blink every 2
seconds instead of current time. After 23.5 hours has passed,
"NO TIME" will appear.
• "??" will blink every 2 seconds instead of the current time,
after 4 hours have passed from the time when the time was
manually programmed. The manually programmed time is
held for only 23.5 hours, and after that, "NO TIME" will ap-
pear.
"LOCAL" appears when the offset time is set.
➥
"MNL" appears when the time is manually programmed.
➥
"UTC" appears when the GGA, GLL and GNS GPS sen-
➥
tence format is included in the GPS signal.
The date information appears when
➥
tence format is included in the GPS signal.
"NO TIME" appears when no GPS receiver is connect-
➥
ed, and no time is manually input.
!5 POSITION INDICATOR
!6 SCAN INDICATOR
the RMC GPS sen-
PANEL DESCRIPTION
➥ Shows the current position when a GPS receiver is
connected, or the position is manually programmed.
• When the GPS position is invalid, "??" may blink every 2 sec-
onds instead of position. The last position is held for only
23.5 hours, and after that, "NO POSITION" will appear.
• "??" will blink every 2 seconds instead of position, after 4 hours
have passed from the time when the position is manually pro-
grammed. The manually programmed position is held for only
23.5 hours, and after that, "NO POSITION" will appear.
➥ "NO POSITION" appears when no GPS receiver is
connected, and no position is manually input.
"SCAN 16" appears during a Priority scan; "SCAN" ap-
➥
pears during a Normal scan. (p. 17)
"DUAL 16" appears during Dualwatch; "TRI 16" appears
➥
during Tri-watch. (p. 18)
