Camera and Electronic Products for Integrators
CeilingVIEW 70 PTZ
Integrated, Recessed Installation Pan/Tilt/Zoom Ceiling Camera System
INTRODUCTION
INTENDED USE
SAVE THESE
INSTRUCTIONS
Ⓒ2006 Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and
pricing are subject to change without notice. CeilingVIEW, WallVIEW, EZCamera, Quick-Connect and PowerRite are registered
trademarks of Vaddio, Inc. All other trademarks are property of their respective owners. Form Number 010-2304-000 Rev. E
Figure 1: Vaddio
CeilingVIEW 70 PTZ
Camera System
partially recessed
into the ceiling
Vaddio's CeilingVIEW 70 PTZ camera system is designed to
provide system integrators with an easy to install, partially
recessed, in-ceiling camera system (see Figure 1). The system
features a Sony
EVI-D70 PTZ Camera mounted into a shallow
®
recessed, metal ceiling camera enclosure with ceiling tile support
and is equipped with Vaddio's EZCamera™ Cabling System which
allows the integrator to use Cat. 5 cabling to run power, video and
camera control.
IR Remote Control or RS-232 can control the camera pan/tilt/zoom
and electronic functions. The VISCA control interface is included to
allow the camera to work with any other VISCA compatible control
device that supports the full range of motion that the camera
supplies. The PowerRite™ power supply regulates the right amount
of power needed for the camera over the Cat. 5 cabling.
Before operating the Vaddio CeilingVIEW 70 PTZ, please read the
entire manual thoroughly. The camera system was designed, built
and tested for use indoors in a suspended acoustic tile ceiling, and
with the provided power supply. The use of a power supply other
than the one provided or outdoor operation has not been tested and
could damage the camera and/or create a potentially unsafe
operating condition.
The information contained in this manual will help you install and
operate your Vaddio CeilingVIEW 70 PTZ. If these instructions are
misplaced, Vaddio keeps copies of Specifications, Installation and
User Guides and most pertinent product drawings for the Vaddio
product line on the website. These documents can be downloaded
from
www.vaddio.com
Installation and User Guide
free of charge.
Advertisement
Table of Contents
Related Manuals for VADDIO CeilingVIEW 70 PTZ
Summary of Contents for VADDIO CeilingVIEW 70 PTZ
- Page 1 Ⓒ2006 Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and pricing are subject to change without notice. CeilingVIEW, WallVIEW, EZCamera, Quick-Connect and PowerRite are registered trademarks of Vaddio, Inc. All other trademarks are property of their respective owners. Form Number 010-2304-000 Rev. E...
-
Page 2: Important Safegaurds
To reduce the risk of electric shock, do not immerse in water or other liquids and avoid extremely humid conditions. Use only the power supply provided with the CeilingVIEW 70 PTZ camera system. Use of any unauthorized power supply will void any and all warranties. - Page 3 24" BRACKET 6) Using the supplied thumbscrews and washers, attach the support rails to the CeilingVIEW 70 PTZ camera (see Figure 4). Place rail edge between two washers and tighten thumbscrew securely. Note: The thumbscrew sits on top of the rail, not through the holes on the rail.
- Page 4 Output to PowerRite Power Display Supply 8) If needed, Cat.5 plenum rated cable(s) may be purchased from Vaddio to connect your camera to a serial control daisy-chaining between multiple cameras (see Figure 6). RS-232 Control Figure 6: Daisy Chain Control...
-
Page 5: Controlling The Camera
The Sony RM-EV100 IR Remote Controller controls the following IR Remote functions when used with a CeilingVIEW 70 PTZ (see Figure 9). A fresh set of AA batteries (not included) should be installed in the provided Sony remote control. To operate, aim remote at camera and depress desired button. - Page 6 Cat.5 cable from the RS-232 IN jack on the camera to your control Systems system using the Cat.5 to DB9 serial adapter supplied by Vaddio. If you are controlling more than one camera, plug the Cat.5 cable from the RS-232 OUT jack on the first camera to the RS-232 IN jack on the second camera.
-
Page 7: Specification
None the first camera, x = 2 for the second camera, etc… The control codes for the CeilingVIEW 70 PTZ are the same codes used with the Control EVI-D70 pan/tilt/zoom camera. Vaddio is not translating these codes and does Disclaimer... -
Page 8: Command List
Direct 8x 01 04 4B 00 00 0p 0q FF pq: Iris Position CAM_Gain Reset 8x 01 04 0C 00 FF Gain setting 8x 01 04 0C 02 FF CeilingVIEW 70 PTZ - Document 010-2304-000 Rev.E Page 8 of 14... - Page 9 8x 01 04 75 02 FF Mute ON/OFF CAM_Mute 8x 01 04 75 03 FF On/Off 8x 01 04 75 10 FF CAM_Display 8x 01 04 15 02 FF Display On/Off CeilingVIEW 70 PTZ - Document 010-2304-000 Rev.E Page 9 of 14...
- Page 10 8x 01 06 03 vv WW 0Y 0Y 0Y Relative Position 0Y 0Z 0Z 0Z 0Z FF Home 8x 01 06 04 FF Reset 8x 01 06 05 ff CeilingVIEW 70 PTZ - Document 010-2304-000 Rev.E Page 10 of 14...
- Page 11 CeilingVIEW 70 PTZ and other Vaddio products to support the Sony Daisy-chain control standard (see Figure 11). Figure 11: RS-232 IN pin-outs for RJ-45 connector on back of CeilingVIEW 70 PTZ Do not attempt to take the camera module apart (other than for the CARE AND reasons stated in the manual).
-
Page 12: Troubleshooting
TROUBLESHOOTING Problem Questions for Troubleshooting Is the Vaddio supplied power supply connected to a working AC wall outlet? Is Vaddio power supply securely connected to wall plate or Quick Connect box? No image Is the Category 5 signal cable securely connected to the Quick Connect... -
Page 13: Warranty Information
Products not under warranty - Payment arrangements are required before outbound shipment for all out of warranty products. *Vaddio manufactures its hardware products from parts and components that are new or equivalent to new in accordance with industry standard practices. - Page 14 Toll Free: 800-572-2011 ▪ Phone: 763-971-4400 ▪ FAX: 763-971-4464 www.vaddio.com Ⓒ2006 Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and pricing are subject to change without notice. CeilingVIEW, WallVIEW, EZCamera, Quick-Connect and PowerRite are registered trademarks of Vaddio, Inc.
