Operator's Manual
Model P30/S30 Series
This manual contains information for the safety
IMPORTANT
of persons and property. Read it carefully before
assembly and operation of the equipment!
Spyker Spreaders
Contact Us at 800.972.6130
©2010 Spyker Spreaders/A Brinly-Hardy Co.
1008146 Rev. A

Advertisement

loading
Need help?

Need help?

Do you have a question about the S30 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SPYKER S30 Series

Summary of Contents for SPYKER S30 Series

  • Page 1 Operator's Manual Model P30/S30 Series This manual contains information for the safety IMPORTANT of persons and property. Read it carefully before assembly and operation of the equipment! Spyker Spreaders Contact Us at 800.972.6130 ©2010 Spyker Spreaders/A Brinly-Hardy Co. 1008146 Rev. A...
  • Page 2 Hopper Explosion Rate Gate Explosion Frame Explosion 1008146 Rev. A...
  • Page 3 Spinner/Axle Explosion 1008146 Rev. A...
  • Page 4 Part Number Qty Description Part Number Qty Description 05-94-0064 Nylon Washer 05-288-1027 Nylon Pin Retainer SS-91-0004 1/4-20 Nylon Locknut, 05-90-0097 #10-24 x 5/8" Flange Head Bolt, SS 1007745-01 Towtube, Polished 05-91-0008 #10-24 Nylon Locknut, 1007744-10 Towtube, Painted 05-94-0037 Gear Box Cover Front 1007746-01 Control Handle, Polished 05-94-0038...
  • Page 5 Install spinner to spinner shaft. Press down on spinner until it snaps into place on the roll pin, Figure 1. Install axle/transmission assembly into frame as shown, Figure 1. IMPORTANT! Note the orientation of the axle/transmission assembly is critical. See the hole locations in Figure 1. One side has hole near the end of the axle, the other Figure 1 next to the frame.
  • Page 6 On the other side of the axle install a wheel washer and rue ring locking pin, Figure 4. Figure 4 Place hopper onto frame. IMPORTANT! Note orientation of rate dial. Be sure to slide spinner shaft into hopper, Figure 5. Insert 1/4"...
  • Page 7 10. Install Hitch Tow Bar onto frame, Figure 7. Attach Figure 7 with 1/4-20 x 1-3/4" Bolt and 1/4" Nylon Insert Locknut. 11. Install Hitch Plates to end of Tow Bar using 1/4-20 x 1-3/4" Bolts and 1/4" Nylon Insert Locknuts, Figure 8.
  • Page 8 16. Turn Control Bracket assembly sideways as shown, Figure 11. Install end of linkage into rate gate bracket. Figure 11 17. Install front of control lever assembly onto Tow Bar with 1/4-20 x 1-3/4" Bolt, 1/4" Washer (one on each side of tow bar) and 1/4" Nylon Insert Locknut, Figure 12.
  • Page 9 18. Install Frame Braces to Frame using 1/4-20 x 1-3/4" Bolt, 1/4" Washer (one on each side) and 1/4" Nylon Insert Locknut, Figure 13. 19. Attach Frame Braces to Tow Tube/Control Lever Assembly using 1/4-20 x 2" Bolt, 1/4" Washers (one on each side), and 1/4"...
  • Page 10 READ BEFORE USING OPERATE SAFELY Keep bystanders away when you operate this machine. Do not wear loose fitting clothing that can get caught in moving parts. Use this machine for intended purpose only. Always wear eye protection when operating the Do not let children or an untrained person operate equipment.

  • Page 11: Read Before Using

    READ BEFORE USING Become Familiar With The Operation Of The Spreader Before You Put Material In The Hopper • Practice walking with the spreader, opening and dial setting on the low side. If the setting proves to closing the rate gate at the appropriate times. be too low, cover the area more than one time.
  • Page 12 READ BEFORE USING • Wear proper clothing and safety equipment while handling or applying chemicals. • Prohibit all smoking, drinking, and eating around Header chemicals. • When spreading products containing herbicides, exercise extreme caution with respect to careless spreading and to wind-drift. Contact Of Some Products On Some Plants Can Be Fatal.
  • Page 13 ACCUWAY - What It Does The Accuway Spread Pattern Equalizer Balances the spread pattern - Bulls Eye - Dead to the Center of the Spreader. All products. All spreading conditions. Skewing is eliminated. Does not change the spread width. ACCUWAY - How It Works Accuway shifts the material placement on the spreader spinner fan.
  • Page 14 NOTE: Dial Settings Are Approximate Only ! Dial Settings Dial Settings Full Rate Half Rate Lbs. per Once Over Twice Over Product Particle Size 1000 sq. ft. Fine Pellets Mixed Fine Pellets Small Pellets Nitrogen Pellets Medium Size Medium Pellets And Granuals Large Heavy Pellets...

  • Page 15: Troubleshooting

    TROUBLESHOOTING Spreader does not sit flat The "feet" or the flattened Using a hammer or pliers, portion of the spreader hopper bend the feet to be equal with support tubes are not bent each other. equally. Deflector shut off is binding Shut off plate is jammed with Thoroughly wash out hopper and will not open/close...

  • Page 16: Year Limited Warranty

    Spyker Spreaders will not be liable for any loss, damage or expense including, but not limited to, consequential or incidental damages, arising from the operation, condition or use of the item.

This manual is also suitable for:

P30 seriesP30S30
