OPeRATOR'S MANuAl
Model S60-12020 Push Spreader
Spyker Spreaders
Contact us at 800.972.6130
www.spyker.com
IMPORTANT
!
!
This manual contains information for the safety of persons and property.
Read it carefully before assembly and operation of the equipment!
©2022 Spyker Spreaders/A Brinly-Hardy Co.
Page 1
1008290-G
Advertisement
Table of Contents
Related Manuals for SPYKER PRO Series
Summary of Contents for SPYKER PRO Series
- Page 1 Model S60-12020 Push Spreader Spyker Spreaders Contact us at 800.972.6130 www.spyker.com IMPORTANT This manual contains information for the safety of persons and property. Read it carefully before assembly and operation of the equipment! ©2022 Spyker Spreaders/A Brinly-Hardy Co. Page 1 1008290-G...
-
Page 2: Table Of Contents
Table of Contents + Safety table Of COntentS Operate Safely Safety ..... . . 2 Read Before using: Part list ..... 3 • Keep bystanders away when you operate this machine. -
Page 3: Part List
Dual Handle Weld Polished 1001414 Decal Mulch-n-more 1008269 Rod, Control 1008267 Coupling 1000198 Felt Washer 1008067 Decal Spyker Square Blue 1000223 Agitator Wire 1001255 Screw 1/4-20 X 1"HexHd,SS 1000607 Spinner - Drilled (black) 1001351 Washer, 1/4" SS 1001237 Bolt, 1/4-20 X 2-3/4"... -
Page 4: Part Explosions
Part Explosions DO NOT RETURN PRODUCT IF YOU ARE MISSING PARTS. Please Call: 1 (800) 972-6130 HOpper explOSiOn rate Gate explOSiOn Handle explOSiOn English Manual Page 4 1008290-G... - Page 5 Part Explosions DO NOT RETURN PRODUCT IF YOU ARE MISSING PARTS. Please Call: 1 (800) 972-6130 Spinner/axle explOSiOn frame explOSiOn *As needed for shimming *As needed for shimming English Manual Page 5 1008290-G...
-
Page 6: Assembly
Assembly 1a. Remove clips from axles on the outside of axle Install the Cross Braces to frame as shown, frame assembly. Figure 2. Install using four 1/4" x 1-1/2" Bolts and Locknuts. Install wheel washer on each end of axle. Fig. - Page 7 Assembly 6a. Install two agitator wires on the upper spinner shaft. Turn handle/linkage assembly sideways and The larger agitator goes on the top/end of the shaft. insert end of linkage into rate gate linkage, Note orientation of the agitator on page 9. Figure 4.
-
Page 8: Troubleshooting
Binding and Will Not plates with water. Ensure debris is not stuck Open / Close Properly between shut-off plate and rate gate plate. A digital calibration calculator is available online. To access, scan this QR code with your smart phone or visit: www.spyker.com/spyker-spreaders-calibration English Manual Page 8 1008290-G... -
Page 9: Dial - General Info
Use and Care read befOre uSinG Become familiar with the operation of the spreader Before you put material in the hopper. • Practice walking with the spreader, opening and CONTACT OF SOMe PRODuCTS ON closing the rate gate at the appropriate times. SOMe PlANTS CAN Be FATAl • Travel at a constant speed and operate the If a dial setting is not found, use the size and weight... -
Page 10: General Tips For Use
Use and Care read befOre uSinG NOW yOu ARe ReADy TO PuT • Leftover fertilizer can be spread under trees and other high feeding areas without showing "edge of MATeRIAl IN The hOPPeR spread" lines. WARNING: AvOid iNjuRY! Chemicals can be dangerous. -
Page 11: Dial Setting Chart
1,000 4 lbs. 1,000 3.75 Pensacola Bahia 5 lbs. 1,000 4.75 6 lbs. 1,000 4.25 A digital calibration calculator is available online. To access, scan this QR code with your smart phone or visit: www.spyker.com/spyker-spreaders-calibration English Manual Page 11 1008290-G... -
Page 12: Warranty
Warranty 1 yeAR lIMITeD WARRANTy This is warranted to the original purchaser only. Spyker will replace parts with defects in materials and workmanship, for a period of one year from the date of purchase. For Spyker Spreaders, a Brinly-Hardy Company, products employing metal gear systems,...
