SPYKER S60-12020 Operator's Manual

Hide thumbs Also See for S60-12020:
Table of Contents

Advertisement

Quick Links

Download this manual
Operator's Manual
Model S60-12020
This manual contains information for the safety
IMPORTANT
of persons and property. Read it carefully before
assembly and operation of the equipment!
Spyker Spreaders
Contact Us at 800.972.6130
©2011 Spyker Spreaders/A Brinly-Hardy Co.
1008290 Rev. B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S60-12020 and is the answer not in the manual?

Questions and answers

Related Manuals for SPYKER S60-12020

Summary of Contents for SPYKER S60-12020

  • Page 1 Operator's Manual Model S60-12020 This manual contains information for the safety IMPORTANT of persons and property. Read it carefully before assembly and operation of the equipment! Spyker Spreaders Contact Us at 800.972.6130 ©2011 Spyker Spreaders/A Brinly-Hardy Co. 1008290 Rev. B...
  • Page 2 Hopper Explosion 28 26 Rate Gate Explosion Handle Explosion 1008290 Rev. C...
  • Page 3 Spinner/Axle Explosion Frame Explosion *As needed for shimming 1008290 Rev. C...

  • Page 4: Rate Gate

    1008269 Rod, Control 05-93-0109 Decal Mulch-n-more SS-92-0002 Felt Washer 1008267 Coupling SS-96-0003 Agitator Wire 1008067 Decal Spyker Square Blue 05-220-0140 Spinner - Drilled (black) 05-90-0047 Screw 1/4-20 X 1"HexHd,SS 05-90-0017 Bolt, 1/4-20 X 2-3/4" 05-90-0054 Bolt, HexHd 1/4x1-1/2 05-92-0008 Washer, 1/4" SS...

  • Page 5: Rev. C

    Remove clips from axles on outside of axle frame assembly. Install wheel washer on each end of axle. Install Wheel on each side of axle (Valve Stem Out). On the drive wheel side, install 3/16 x 1-3/4" Clevis Pin and Cotter Pin, Figure 1. On opposite side install wheel washer and Rue Ring Locking Pin on outside of wheel.

  • Page 6: Install Linkage To Lever, Figure

    Install linkage to lever, Figure 3. Figure 3 Turn handle/linkage assembly sideways and insert end of linkage into rate gate linkage, Figure 4. Figure 4 Install handle to frame as shown using 1/4" x 1-3/4" Bolts and Locknuts. NOTE: You'll need to orient and install the cable bracket as shown on the left side of the spreader, Figure 5.
  • Page 7 Install two agitator wires on the upper spinner shaft. The larger agitator goes on the top/end of the shaft. Note orientation of agitator on page 9. Install felt washer on shaft below the agitator wires. Slide shaft down through hopper. Install fan and coupler, Figure 6.

  • Page 8: Operate Safely

    READ BEFORE USING OPERATE SAFELY Keep bystanders away when you operate this machine. Do not wear loose fi tting clothing that can get caught in moving parts. Use this machine for intended purpose only. Always wear eye protection when operating the Do not let children or an untrained person operate equipment.

  • Page 9: Read Before Using

    READ BEFORE USING Become Familiar With The Operation Of The Spreader Before You Put Material In The Hopper • Practice walking with the spreader, opening and dial setting on the low side. If the setting proves to closing the rate gate at the appropriate times. be too low, cover the area more than one time.
  • Page 10 READ BEFORE USING to wonder where you are or where you have been. Now You Are Ready To Put Continue until spreading is completed. Material In The Hopper • Left over fertilizer can be spread under trees and WARNING: Avoid Injury! Chemicals can be other high feeding areas without showing "edge of dangerous.
  • Page 11 NOTE: Dial Settings Are Approximate Only ! Dial Settings Dial Settings Full Rate Half Rate Lbs. per Once Over Twice Over Product Particle Size 1000 sq. ft. Fine Pellets Mixed Fine Pellets Small Pellets Nitrogen Pellets Medium Size Medium Pellets And Granuals Large Heavy Pellets...

  • Page 12: Year Limited Warranty

    Spyker Spreaders will not be liable for any loss, damage or expense including, but not limited to, consequential or incidental damages, arising from the operation, condition or use of the item.
