OPERATOR'S MANUAL
SPYVD-80100 Deflector Kit
For use
with the Spyker
SPY100-1S
Push Spreader
Spyker Spreaders
Contact us at 800.972.6130
www.spyker.com
IMPORTANT
!
!
This manual contains information for the safety of persons and property.
Read it carefully before assembly and operation of the equipment!
©2020 Spyker Spreaders/A Brinly-Hardy Co.
Page 1
1018792-E
Advertisement
Table of Contents
Related Manuals for SPYKER SPYVD-80100
Summary of Contents for SPYKER SPYVD-80100
- Page 1 SPY100-1S Push Spreader Spyker Spreaders Contact us at 800.972.6130 www.spyker.com IMPORTANT This manual contains information for the safety of persons and property. Read it carefully before assembly and operation of the equipment! ©2020 Spyker Spreaders/A Brinly-Hardy Co. Page 1 1018792-E...
-
Page 2: Part List
1018706RH Mounting Bracket, RH 1007386 Bolt, Carriage, SS: 1/4”-20 x 3/4” 1018708 Stiffener Plate 1019001 Bolt, HexHd: 1/4”-20 x 1-3/4” 1018738 Spring 1019187 Label, Material Striping 1018740 External Tooth Lockwasher *Not Illustrated ©2020 Spyker Spreaders/A Brinly-Hardy Co. Page 2 1018792-E... -
Page 3: Hardware Identifier
Keep this hardware for the following step. Hook both of the springs (7) through the base of each bracket extension as & illustrated. ©2020 Spyker Spreaders/A Brinly-Hardy Co. Page 3 1018792-E... - Page 4 From the outside and facing in, run a carriage bolt (12), and lock nut (10). Gently flip the spreader over, balancing it on the rim of the hopper and the handles. FLIP SPREADER OVER ©2020 Spyker Spreaders/A Brinly-Hardy Co. Page 4 1018792-E...
- Page 5 Repeat on the other side Do not tighten this nut fully YET and repeat of the deflector. this step on the other side of the deflector. INSIDE EDGE OF THE DEFLECTOR OUTSIDE EDGE OF THE DEFLECTOR ©2020 Spyker Spreaders/A Brinly-Hardy Co. Page 5 1018792-E...
- Page 6 Assembly is complete! the lock nut down the length of this bolt, however, allow a little bit of movement. Repeat on the other side of the deflector. INSIDE EDGE OF THE DEFLECTOR ©2020 Spyker Spreaders/A Brinly-Hardy Co. Page 6 1018792-E...
- Page 7 2. Grasp the deflector (as illustrated here) on both sides and pull toward yourself while raising or lowering to the desired setting. NOTE: Moving the deflector UP increases the spread width. ©2020 Spyker Spreaders/A Brinly-Hardy Co. Page 7 1018792-E...
-
Page 8: Maintenance And Service
In any case, do not pile weight on the spreader, as excess weight over a period of time can distort the tires. Oil Bearings and All Moving Parts Make sure the spreader is running freely! ©2020 Spyker Spreaders/A Brinly-Hardy Co. Page 8 1018792-E...
