SPYKER SPY200T-1P Operator's Manual

Tow spreader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATOR'S MANUAL
Model SPY200T-1P Tow Spreader
Spyker Spreaders
Contact us at 800.972.6130
www.spyker.com
IMPORTANT
!
This manual contains information for the safety of persons and property.
Read it carefully before assembly and operation of the equipment!
©2021 Spyker Spreaders/A Brinly-Hardy Co.
Page 1
1019884-B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPY200T-1P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SPYKER SPY200T-1P

Summary of Contents for SPYKER SPY200T-1P

  • Page 1 OPERATOR'S MANUAL Model SPY200T-1P Tow Spreader Spyker Spreaders Contact us at 800.972.6130 www.spyker.com IMPORTANT This manual contains information for the safety of persons and property. Read it carefully before assembly and operation of the equipment! ©2021 Spyker Spreaders/A Brinly-Hardy Co.

  • Page 2: Table Of Contents

    1-800-972-6130. Warranty ....24 Warranty information on this Spyker attachment can be found in the warranty statement included in this manual.

  • Page 3: Part List

    • Keep all nuts, bolts and screws tight to be sure the equipment is in safe working condition. • Always remove material from hopper before attaching spreader on a vehicle-mounted spreader caddy. ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 3 1019884-B...

  • Page 4: Hardware Identifier

    ......D-146P NOTE: An extra washer (C2) has been provided / may be remaining after assembly is complete. ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 4 1019884-B...
  • Page 5 (x1) ....1019874 1000223 Linkage Rod (x1) ..1019875 ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 5 1019884-B...

  • Page 6: Part Explosions

    Tow Bar 1019873-10 Linkage Pivot R-892-10 Clevis 1019901 Hopper Cover 1020016-10 Tow Bar Brace 1019900 Screen 1000607 Spinner - Drilled (black) 1019895-10 Riser Bar 1020128 Hopper, 200lb └ 1019899 Tow Spreader Gate Assy ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 6 1019884-B...
  • Page 7 Bolt; Hex Head, 1/4 x 1 45M1111P Washer; Flat, 5/16 1019874 Linkage Pin B-3861 Pin; Hitch, 1/2" x 2-1/2" 1019875 Linkage Rod D-146P Cotter; Hairpin, 1/8", #211 1000223 Agitator Wire 1000198 Felt Washer ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 7 1019884-B...
  • Page 8 Rate Gate Link 1019860 Fan Shaft, Tow Spreader 45M0909P Washer, SAE Flat, 1/4" B-3385 Nut, Nylon Lock, #10-24 2M0812P Bolt, Hex Head, 1/4 x 3/4 1000198 Felt Washer B-4785 Nut, Nylon Lock 1/4-20 ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 8 1019884-B...

  • Page 9: Assembly

    Add a 5/8” washer (C2), axle spacer (B2), a second 5/8” washer (C2), then the wheel (C). Secure the wheel in place with the 3/16” clevis pin (E2) and cotter ring (D2), as illustrated. ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 9 1019884-B...
  • Page 10 5/16” x 2” bolts (G2), securing from below with two 5/16 lock nuts (H2). Insert the 1.25” tub plug ( 2) in the end of the towbar. NOTE: These bolts will be tightened on step 8. ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 10 1019884-B...
  • Page 11 - (x2) 5/16” Lock Nuts (H2) NOTE: Secure by tilting the clip down and apply NOTE: This hardware will be tightened on step 8. slight pressure to snap in place around the fan shaft. ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 11 1019884-B...
  • Page 12 Align the pivot plate (K) to the riser bar ( ) as illustrated. Secure with: - (x2) Handle Knobs (W2) - (x1) 1/4” Lock Nylon (R2) - (x2) 1/4” x 1-3/4” Bolts (S2) - (x2) 1/4” Lock Nuts (R2) ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 12 1019884-B...
  • Page 13 (O) that was added on step 15. NOTE: Bolt together snug but not tight. - (x1) Linkage pin (Y2) - (x1) 1/4” Lock Nut (R2) NOTE: Bolt together snug but not tight. ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 13 1019884-B...
  • Page 14 Adjust the position of the two lock nuts (R2) that were added on step 17-A such that the gate is in the no more that 1/16” past the fully closed position. Assembly is complete. Open Closed ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 14 1019884-B...

  • Page 15: Operation Instructions

    THE SPREADER 1. Inflate tires to 20 PSI-30 PSI (1.4 BAR-2.1 BAR) SPECIFICATIONS (138kPa-207kPa) maximum. 200 lb Spreader (SPY200T-1P) 2. Check bushings and bearing surfaces for proper lubrication (See service section). Capacity 3. Be sure controls operate smoothly and spreader Spreader Weight .

  • Page 16: Installing / Removing

    5. Pull or push spreader backward to disengage the hitch clevis from machine hitch, install hitch pin in hitch clevis for storage and secure with 1/8 in. spring locking pin. ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 16 1019884-B...

  • Page 17: Flow Control / Settings

    Full Flow. For half flow application, set flow control dial according to “Half Flow” value shown in appropriate table. Do not set flow dial at half the recommended full flow value. ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 17 1019884-B...

  • Page 18: Spreading Tips

    Because of these variables, the diffuser plate must be set 3. To avoid material loss, fill spreader on a sidewalk, driveway, plastic sheet or cardboard. for each type of application. ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 18 1019884-B...
  • Page 19 Continue to turn knob in small increments until test ice melt to avoid damage to bearings. pattern is centered. 3. After spreading, be sure to thoroughly rinse the ice melt dust from all surfaces, as ice melt is highly corrosive. ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 19 1019884-B...
  • Page 20 Clean and (Refer to “Keys to Uniform Spreading” covered previously oil spreader immediately after each use. in manual). 4. Repeat steps two and three using passes in cross direction to those used previously. ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 20 1019884-B...

  • Page 21: Cleaning / Maintenance

    When spreader is completely dry, lubricate all moving parts, especially spinner drive, hopper bottom, wheel bushings and gears. Reference the Service Section for RECOMMENDED LUBRICANTS procedures. - Multi-Purpose Lithium Grease ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 21 1019884-B...

  • Page 22: Storage

    Salt residue is especially • Lubricate gearbox by applying 3-4 shots of corrosive. Clean and oil spreader grease into grease fitting (4). immediately after each use. ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 22 1019884-B...

  • Page 23: Setting Charts

    5.00 4.75 4.00 6.00 5.00 4.25 Use “Full Flow” Use the “Half Flow” setting when single setting for two pass pass (once over) (twice over) operation operation is planned. and improved coverage. ©2021 Spyker Spreaders/A Brinly-Hardy Co. Page 23 1019884-B...

  • Page 24: Warranty

    WARRANTY 1 YEAR LIMITED WARRANTY This is warranted to the original purchaser only. Spyker will replace parts with defects in materials and workmanship, for a period of one year from the date of purchase. For Spyker Spreaders–a Brinly-Hardy Company, products employing metal gear systems,...
