1. GENERAL INFORMATION

1-1. Introduction and Description

This manual explains the installation, operation and maintenance of the ACOM2000A automatic HF
linear amplifier.
The ACOM2000A is a complete and self-contained linear amplifier which covers all amateur bands
from 1.8 through 30MHz, has automatic self-tune capability, and provides up to 1500W output power
with less than 60W exciter drive. In addition, it has automatic antenna impedance matching capability
for loads up to 3:1 VSWR (2:1 on 160 meters). It features a Remote Control Unit (RCU), contains
nonvolatile memory for settings on up to ten different antennas per frequency segment, and offers
command capability for use with an external automatic antenna selector and/or automatic antenna
tuner. Transmit / receive switching is capable of full break-in operation (QSK) via an internal vacuum
relay.
All indicators and controls (except the primary mains switch and indicator) are available via the RCU.
All command input to the RCU is menu-driven.

1-2. Owner Assistance

If assistance is needed, you should contact your local dealer first. If you still have an issue you need to
discuss with one of ACOM's specialists. The contact information is as follows: fax: (+ 359 2) 920 96 56,
e-mail acom@mail.orbitel.bg, acom@aster.net or by mail: blvd."Nikola Mushanov"-151, 1330 Sofia,
Bulgaria.

1-3. Equipment Supplied and Options

The ACOM 2000A amplifier is shipped in two cardboard cartons. One carton contains the power
transformer; the second carton contains the amplifier. The remote control unit (RCU) is shipped inside
the amplifier in the area where the power transformer will be mounted.
There are three separably-purchasable options available. They are an auxiliary EXTERNAL FAN for
continuous modes of operation (rear panel mount), a DOS APPLICATION for program control via
personal computer and the TECHNICAL SUPPLEMENT to this manual, containing electrical diagrams,
technical details on operation and maintenance, as well as a list of command set and local network rules
for RS232 operation.
The Automatic antenna selector ACOM 2000S and Remote antenna switch ACOM 2000SW are
especially designed to complete your ACOM system.

1-4. Features

Easy to operate. No operator intervention is required when matching antennas or when changing
frequency. Thus the risk of inadvertant errors, such as incorrect antenna selection or failure to change
band switch, is eliminated.
LCD comment display. All amplifier status indicators are explained via detailed text diplayed on the
dot-matrix, back-lighted liquid crystal display (LCD) on the RCU. The HELP sub-menu gives on-board
technical assistance and troubleshooting suggestions, power-on hours etc. LED strips readout direct
peak forward and reflected power. LED indicators are provided for OPERATE/STANDBY and for fault
conditions.
