7. SPECIFICATIONS

7-1. Parameters

a) Frequency Coverage: All amateur bands 1.8-29.7MHz; extensions and/or changes on request.
b) Power Output: 1500W PEP or continuous carrier, no mode limit.
In continuous carrier modes (RTTY etc.) for transmissions longer than 15 minutes (up to several hours
depending on ambient temperature), the optional auxiliary fan must be mounted.
c) Intermodulation Distortion: Better than 35dB below rated output.
d) Hum and noise: Better than 35dB below rated output.
e) Harmonics Output Suppression: Better than 50dB below rated output.
f) Input and Output Impedances:
nominal value: 50 Ohm unbalanced, UHF (SO239) type connectors;
input circuit: broadband, VSWR less than 1.3:1, 1.8-30MHz continuously (no tunings, no switching);
bypass path VSWR less than 1.1:1, 1.8-30MHz continuously;
output matching capability: better than VSWR 3:1 (2:1 for 160m) or greater at reduced output
levels; automated.
g) Automatic Tuning:
Antenna Impedance Matching - less than 3 seconds;
Band Change - less than 1 second;
Segment Change - less than 0.2 seconds.
h) RF Gain: 14.5dB, frequency response less than 0.5dB (50 to 60W drive power for rated output).
i) ALC: grid-current derived, -11V max, rear panel adjustable.
j) Primary Power: 90-132V (100 & 120V nominal taps, 10% tol.) and 180-264V (200, 220 & 240V
nominal taps, 10% tol.), 50-60Hz, single phase, 3500VA consumption at rated output.
k) Complies CE safety and electromagnetic compatibility requirements, as well as FCC-regulations (10
& 12m bands lock provided).
l) Size & Weight (operating): W440mm x D500mm x H180mm, 36kg.
m) Operating environments:
temperature range: 0...+50 degs.Celsius;
humidity: up to 95% @ +35 degs.Celsius.
height: up to 3000m above sea level without output deterioration.
