- Page 1 Installation Guide and Users Manual PS29/PS31 IMPORTANT: Read and save these instructions. NOTICE: Installer: Leave this guide with the homeowner Homeowner: Keep this guide for future reference Wall Mount Range Hood SPAGNA VETRO Rev. 3065u.5a...
-
Page 3: Important Safety Notice
Important Safety Notice Read all Instructions before Installing and operating this appliance • The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background. Installation and electrical wiring must be done by qualified profession- als and in accordance with all applicable codes and standards, including fire-rated construction. - Page 4 Important Safety Notice Read all Instructions before Installing and operating this appliance • Clean ventilating fan frequently. • Always use appropriate cookware and utensils size. • Always use cookware appropriate for the size of the surface element. To reduce the risk of injury to persons in the event of a stove top grease fire: •...
-
Page 5: Table Of Contents
Table of Contents INSTALLATION USE AND CARE Tools needed............3 Troubleshooting...........14 Parts supplied...........4 Use and care information.......15 Venting requirements........5 Specifications..........15 Mount heights & clearance......5-6 Measurements & Diagrams......16-21 MAINTENANCE Calculating vent system length.......6 Venting methods..........7 Cleaning..........22 Electrical requirements........8 Replacing the filter & light bulb....22-23 WARRANTY Preparation............9 Installation..........10-11... -
Page 6: Parts Supplied
Parts supplied: Upper Chimney Lower Chimney Range Hood Chimney Mounting Bracket Qty: 4 PCS Baffle Filters Qty: 2 PCS (30-in models) Qty: 3 PCS (36-in models) Qty: 6 PCS Qty: 4 PCS (30-in models) Qty: 6 PCS (36-in models) Qty: 2 PCS (30-in models) Qty: 3 PCS (36-in models) Qty: 6 PCS Qty:6PCS... -
Page 7: Venting Requirements
Venting Requirements Height & Clearance Chimney- • Vent system must terminate to the outside (roof or side wall). mounting Maximum ceiling clearance • DO NOT terminate the vent system in an at- 110” at 30” hood mounting Bracket height above countertop/ tic or other enclosed area. -
Page 8: Calculating Vent System Length
IMPORTANT: • A minimum of 6” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separate- ly) must be used to maintain maximum airflow efficiency. • Always use rigid type metal/aluminum ducts if available to maximize airflow when connecting to provided duct. -
Page 9: Venting Methods
Venting Methods • This range hood is factory set for venting through the roof or wall. • Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. IMPORTANT: • NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. -
Page 10: Electrical Requirements
Electrical Requirements IMPORTANT: Observe all governing codes and ordinances. (Please consult with a qualified electrician for 220-Volt 50 Hz voltage) It is the customer’s responsibility: • To contact a qualified electrical installer. • To assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/ NFPA 70 —... -
Page 11: Preparation
Preparation Advanced Preparations: Read the entire installation guide and users manual thoroughly, understand instructions and warnings. Be familiar with the controls of the range hood by reading through Range Hood Operations, Page 12. Place the range hood on a flat, stable surface. Connect the range hood to a designated standard outlet (please refer the product label for the suitable voltage of this unit) and verify no debris has entered the vent openings, then turn on the range hood. -
Page 12: Installation
Installation Figure 1 Installations (refer to Page 4 for parts): Measure the distance between stove top and the bottom of range hood. A distance of 28” to 31” is recommended*. *Due to different ceiling height configurations, recom- mended height may not be applicable. Height &... -
Page 13: Installation
Installation (Continued) Store excess wires in the wiring box. Install both chimneys and tighten screws to secure the lower chimney to the range hood as shown in Figure 5. To avoid scratching the chimney, extend the upper chimney slowly and carefully to the chimney-mounting bracket and tighten screws as shown in Figure 6. -
Page 14: Range Hood Operations
Range Hood Operations Control Panel Layout and Buttons Configurations: LCD Panel Light Decrease Power-Off Increase Delay Auto Function Remote Control Sensor In addition to the remote control feature, this range hood is also equipped with a heat sensor that will self-calibrate in 5 seconds when the range hood is first electrically activated and beeps when self-calibration is done. - Page 15 Range Hood Operations (Continued) Control Panel Layout and Buttons Configurations: LCD Panel Light Decrease Power-Off Increase Delay Auto Function Remote Control Sensor Activating Light Function: • Press Light button once to turn on the lights, and once again to turn off the lights. CAUTION: DO NOT touch the lights until switched OFF and cooled.
-
Page 16: Troubleshooting
Troubleshooting If the range hood or halogen light does not operate • Check if the range hood has been plugged in, make after installation: sure that all power has been turned back ON, fused not blown and all electrical wiring are properly con- nected. -
Page 17: Use And Care Information
Use and Care Information Operations: • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. • Always leave safety grills and filters in place. Without these components, operating blowers could catch on to hair, fingers and loose clothing. -
Page 18: Measurements & Diagrams
Measurements and Diagrams Page 16... - Page 19 • All measurements in parenthesis are in millimeter. • All inch measurements are converted from millimeters, thus inch measurements are estimated. Overall: Page 17...
- Page 20 • All measurements in parenthesis are in millimeter. • All inch measurements are converted from millimeters, thus inch measurements are estimated. Overall without Chiminey: Page 18...
- Page 21 Hood-mounting Bracket: 9” (230) 9-11/16” (246) Circuit Diagram: Page 19...
- Page 22 Range Hood Assembly: Description Quantity Hood-Mounting Bracket Hood Body Light Control Panel Oil Tunnel Blow Assembly (Motor, Fan Blade, Protective Grill and Squirrel Cage) Electrical Assembly Stainless Steel Spacer Baffle Filter Power Cord Ducting Transition Chimney Set (Upper + Lower Section) Chimney-Mounting Bracket Page 20...
- Page 23 Blower Assembly: Description Description Motor Locknut Spuirrel Cage Protective Grill Fan Blade Page 21...
-
Page 24: Cleaning
Maintenance SAFETY WARNING: Never put your hand into area housing the fan while the fan is operating! For optimal operation, clean range hood and all baffle/spacer/filter/grease tunnel/oil container regularly. Regular care will help preserve the appearance of the range hood. Cleaning Exterior surfaces: •... - Page 25 Maintenance (Continued) Replacing the Light Bulb Using the Inner Ring Opener: • Make sure the range hood is unplugged or turn OFF breaker. • Make sure the lights are cool to touch, carefully align the arrow on the inner ring with the arrow on the outer ring where it says OPEN with the Inner Ring Opener as shown in Figure 1.
-
Page 26: Coverage & Exceptions
Warranty TO OBTAIN SERVICE UNDER WARRANTY: You must present proof of original purchase date. Please provide an original dated proof of purchase (sales receipt / invoice) in order to obtain service under warranty. One Year Parts Warranty: For one year from the date of original purchase, your local reseller will provide free of charge, non-consumable replace- ment parts or components that failed due to manufacturing defects. -
Page 27: Disclaimer & Contact Us
Disclaimer Carefully inspect all items for damages before accepting delivery. note any damages on the freight bill or express receipt. request name and signature of the carrier’s agent and keep copy to support your claim. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately. - Page 28 SPAGNA VETRO Spagna Vetro Appliances Inc Burnaby ,BC , Canada www.KitchenHoods.ca tel. 604 430 5252...
