Specifications

CPU

Memory

Boot loader
Data storage
Ethernet
MiniPCI slot
Expansion
CompactFlash slots
Serial port
LEDs
Beeper
Power at the board
Power at the case
Fans
Dimensions
Weight
Temperature
Humidity
Power consumption

Hardware Guide

Memory and Storage Devices

Memory
There is no onboard memory, but the device has a SODIMM slot for one DDR2 module, it is recommended to
use modules with at least 667MHz (PC-4200). The RB1100 device supports modules of up to 2GB, but due
to software limitations, RouterOS will be able to use only 1.5GB of it.

Storage Device

The device is equipped with one 512MB NAND nonvolatile memory chip.

microSD slot

The board has one microSD card slot which supports microSD and microSDHC cards for expanding the
storage in RouterOS
4
RouterBOARD 1100/AH Series User's Manual
RB1100: MPC8544 800MHz network processor
RB1100AH: MPC8533 1066MHz network processor with IPsec acceleration
SODIMM slot, no onboard module
512MB onboard NAND memory chip
Thirteen 10/100/1000 Mbit/s Ethernet ports supporting Auto-MDI/X
One microSD card slot on board, accessible by opening the case
One DB9 RS232C asynchronous serial port
Power jack: 12-24VDC; PoE on Ether12: 12-24VDC
JP1202 and JP1204 - 12V; 0,2A max.
JP1201 and JP1203 - 3,3V; 0,3A max.
Only one Fan in each pair will rotate, other will start when first fails.
Only one pair can be connected at the same time (two fans).
1U rackmount case: 44 x 176 x 442 mm
365g board only, 1275g assembled with case
Operational: -20°C to +65°C (-4°F to 149°F)
Operational: up to 70% relative humidity (non-condensing)
RouterBOARD 1100/AH
RouterBOOT
-
-
Power and User LED
+
IEC C14 jack: 110-220VDC
Board: 135 mm x 291 mm
12W min/25W max
