- Page 1 Self-install Instructions PureFiber-ADSL Failover (Upgrade from ADSL) - Self Install Guide Skyway West - May 2019...
- Page 2 This is what your service Your current setup setup will look like immediately after Telus completes their PureFiber Installation Wall Jacks Please follow this guide to Fiber ONT fully complete the (Provided by Telus) installation of your connectivity solution. IMPORTANT: You will lose connectivity during this process.
- Page 3 RouterBoard Management Router (Sent to you by Skyway) You will receive this RouterBoard management router from Skyway West. Please connect it (according Panel to this guide) in order to complete your setup. You may also receive other equipment from Skyway, depending on the specifics of your solution.
- Page 4 Don’t forget to plug in! All devices described within this guide must be plugged in to appropriate power outlets. The diagrams herein do NOT show power cords in order to keep them simple and easy to understand.
- Page 5 1. Plug your ADSL Modem to the wall jack, if required Wall Jacks Fiber ONT (Provided by Telus) Actiontec WiFi Router Modem...
- Page 6 2. Unplug your Fiber ONT from your WiFi router Wall Jacks An Optical Network Terminal Fiber ONT (ONT) is the device that a (Provided by Telus) fiber line terminates into, and converts optical data into ethernet-protocol data. Actiontec WiFi Router Modem...
- Page 7 PureFiber Failover RouterBoard Port Diagram Plug the Fiber ONT into port ONE (Internet / PoE port) the Skyway RouterBoard. Wall Jacks Plug the ADSL or Cable Fiber ONT modem into port (Provided by Telus) Skyway RouterBoard the Skyway RouterBoard Management Router...
- Page 8 LAN directly through our management router. Fiber ONT (Provided by Telus) In order to reach your internal Skyway RouterBoard Management Router network, WiFi traffic is tunneled to Skyway and returns through your Internet connection to your LAN firewall.
