4.1 Introduction

This section is a detailed list of all parameters that can be changed and tests that can
be initiated from the touch screen.
Section 1 and 2 of this manual describe in detail the most commonly used touch
screen manipulation.
This section may be used as a reference for locating a certain parameter setting or
test. The less frequently used parameters are also explained in this section.

4.2 Action Menu

Actions
Set Origin
Load
Roll
Reset
Media
Alignment
Replot
Cut off
Most of the explanation of this menu is covered in previous sections.
Set Origin: Used to change the origin of the tool carriage on a loaded piece of media.
After this button is pressed, arrow keys will appear to allow the user to go to the new
origin.
Load: The loading procedure is explained in section 1.5.4.
Reset: Used to interrupt an ongoing job.
Media alignment: Starts the loading procedure for contour cutting; see section 3.3.6.
Replot: Each job is stored in the cutter's memory until a new job is sent. Pressing
replot allows the job to be replotted. After this button is pressed, the user may choose
the number of replots. The replot button does not work if there is no job in the
memory, or if the previous job was larger than the cutter's memory.
Cut off: Moves the media till after the last cut vector and cuts off from the roll with the
cut off knife.

Detailed Operation

Sheet Extended
FIG 4-1
4-1

ACTION MENU

4 Detailed Operation
OPOS Barcode Roll up media
(*) Only when roll up is enabled
4-1
