S CLASS™ cutter
•
Interchangeable pouncing tool with its own pouncing strip.
•
Integrated OPOS positioning and alignment system.
•
Interchangeable pen for producing preview plots of sign designs on paper.
•
Adjustable knife pressure and offset settings controlled by microprocessor.
•
Communication with host computer via standard serial USB 1.1 or RS-232.
•
320 x 240 touch screen panel for convenient operator control.
•
Metric or English units.
•
User-addressable curve resolution: 0.1 mm, 0.025 mm, 0.001" or 0.005".
•
Menu mode for selection of the cutter's power-up operating configuration.
•
Wide variety of cutting speeds (in metric or English units).
•
Up to eight separate user configurations stored in non-volatile memory.
•
Media support system for automatic loading of media with optional "shuffling" to
guarantee tracking of longer signs.
•
Automatic media pull from roll.
•
Media sensing.
•
Concatenation and curve smoothing to obtain better cut quality.
•
Multiple recut feature.
•
Tool calibration tests.
•
Overcut for easy weeding, OptiCut for prolonged drag knife life.
•
Stand and basket.
•
Automatic cut sheet feature.
