S CLASS™ cutter
6. Press
to confirm the new value, or press
changing the value.
7. Press
to get online again.
8. Register the markers and cut the first contour as described in sections 3.3.5 and
3.3.6.
The cutter will stop after the first contour has been cut and come online again.
9. Press
The main action menu will appear on the screen.
10. Press
11. Use
or
12. Press
to confirm the new value, or press
OPOS will sense the markers for the second contour and then cut that contour.
This process of sensing and cutting will repeat automatically until all remaining
contours have been cut.
3.4.2 Cutting the same graphic on multiple media sheets
If the same graphic design has been printed on a multiple sheets, then this feature
can be used.
NOTE: The sheets should be more or less the same size, and the graphics on
them should be oriented and positioned the same way.
First, load the media and check that the parameters of the OPOS markers are set
correctly.
Cutting the same graphic on multiple media sheets:
1. Press
The main option menu will appear on the screen.
2. Press
The different configuration menus will appear on screen.
Contour Cutting
.
.
to change the number of recuts displayed.
.
.
User's Manual
to exit the menu without
to exit.
3-14
