Specifications; Cutter; Media; S Class™ Cutter Specifications - Summa S CLASS User Manual

S CLASS™ cutter

6.2 Specifications

6.2.1 Cutter

S75(T)
mm
Height 1110
Width 1410
Depth
680
folded basket
Depth
1080
open basket
Kg
Weight 49.5

6.2.2 Media

mm
Width 60 - 840
Maximum
742
(*)
cutting width
Min margin
25
(**)
left/right
Front margin 45
Rear margin
Sensor on 45
Sensor off 33
Tracking ± 0.1mm up to 12 m (vinyl < 760mm)
(***)
Performance ± 0.004" up to 40 feet (vinyl < 30")
0.05mm to 0.25mm
Media Thickness
0.002" to 0.01"
(*)
Maximum cutting width in normal mode, 'oversize mode' allows a wider cutting area
(**)
For positioning of the pinch rollers (see section 1.5.1).
(***)
Media lengths greater than the specified length can be handled, but compliance with specifications is
not guaranteed (will be dependent on media type, media size and other parameters).
Specifications
S120(T)
inch mm
43.7 1110
55.5 1870
26.8 680
42.5 1080
pounds Kg
109 61.5
TABLE 6-1
6-1 S CLASS™ CUTTER SPECIFICATIONS
S75(T) S120(T)
inch mm
2.4 - 33 115 -1300 4.5 - 51 170 -1450 6.7 - 57 170 -1680 6.7 - 66
29.2 1200
1 25
45 45
1.75 45
1.3 33
Up to 0.8mm (0.03" ) with sandblast drag knife
Up to 1.2mm (0.047" ) with sandblast tangential knife
TABLE 6-2
6-2 S CLASS™ MEDIA SPECIFICATIONS
S140(T)
inch mm inch
43.7 1110 43.7
73.6 2021 79.6
26.8 680 26.8
42.5 1080 42.5
pounds Kg pounds
135.6 65.5 144.5
S140(T)
inch mm inch
47.2 1350 53.1
1 25
45 45
1.75 45 1.75
1.3 33
± 0.1mm up to 4 m (vinyl >760mm)
± 0.004" up to 13 feet (vinyl >30")
User's Manual
S160(T)
mm inch
1110 43.7
2250 88.6
680 26.8
1080 42.5
Kg pounds
71 156.5
S160(T)
mm inch
1580 62.2
1 25 1
45 45 45
45 1.75
1.3 33 1.3
6-3
