S CLASS™ cutter

3.4 Automating Tasks with OPOS

OPOS allows the user to automate certain tasks, thus reducing user intervention and
production time. When cutting multiple graphics, the user only needs to maneuver the
OPOS sensor above the Origin marker of the first graphic; cutting subsequent
graphics does not require additional user input.
There are two multiple-job situations in which OPOS can be used:
When cutting multiple (copies of a) graphic(s) on the same media roll.
When cutting the same graphic on multiple media sheets.
Most automated tasks are organized from within the cutting software. However, when
the same graphic contour needs to be cut out, then the automatic tasks also involve
some manual manipulation.
Before using the automating features, note the amount of your cutter's RAM. If the
cutter's RAM is greater than the job's file size, then the automating features may be
used. If the cutter's RAM is less than the job's file size, then the automating features
may not be used.

3.4.1 Cutting multiple copies of a graphic on the same roll

If the same graphic design has been printed on a roll with equal distance between the
different graphics, then this feature can be used.
First, load the media and be sure the parameters of the OPOS markers are set
correctly.
Cutting multiple copies of the same graphic on the same media roll:
1. Press
The main menu will appear on screen.
2. Press
The configuration menus will appear on screen.
3. Press
The general settings will appear on the screen.
4. Press
The current value of the recut offset will appear on screen.
5. Use or
cut vector and the beginning of the first marker).
Contour Cutting
.
.
.
.
to change the recut offset (the distance between the last
User's Manual
3-13
