VLAN
Converting Port VLAN to Tag VLAN (continued)
VLAN ID: 1
Name : Default VLAN
Status : Active
-----------------------------------------------
PORT | MODE
-----------------------------------------------
1 | UNTAGGED |
2 | UNTAGGED |
3 | UNTAGGED |
4 | UNTAGGED |
5 | UNTAGGED |
6 | UNTAGGED |
7 | UNTAGGED |
VLAN ID: 10
Name : engineering
Status : Pending
-----------------------------------------------
PORT | MODE
-----------------------------------------------
3 | UNTAGGED |
4 | UNTAGGED |
5 | UNTAGGED |
VLAN ID: 20
Name : sales
Status : Pending
-----------------------------------------------
PORT | MODE
-----------------------------------------------
3 | UNTAGGED |
4 | UNTAGGED |
5 | UNTAGGED |
VLAN ID: 30
Name : marketing
Status : Pending
-----------------------------------------------
PORT | MODE
-----------------------------------------------
3 | UNTAGGED |
4 | UNTAGGED |
5 | UNTAGGED |
start vlan=all
ML810(tag-vlan)##
All pending VLAN's started.
set-port port=3-5 filter status=enable
ML810(tag-vlan)##
Ingress Filter Enabled
show vlan type=tag
ML810(tag-vlan)##
VLAN ID: 1
Name : Default VLAN
Status : Active
(continued on next page)
10–16
| STATUS
UP
DOWN
DOWN
DOWN
DOWN
DOWN
UP
| STATUS
DOWN
DOWN
DOWN
| STATUS
DOWN
DOWN
DOWN
| STATUS
DOWN
DOWN
DOWN
Note that the VLANs are not started as yet.
Adding the VLAN does not start it by
default.
