2.3 16-CH Remote Controller

Key Title
Press the button to enter into manual record.
REC
Press the button to enter into record search menu
SEARCH
Enter into Quad display
2×2
Enter into 9-split display
3×3
Enter into 16-split display
4×4
Enter into dwell time display
AUTO
Channel select; numeric key
0~9
Multiple CH display (Quad, 9-split, 16-split and full
DISPLAY
screen display）
MODE
Up direction key
▲
▼ Down direction key
Left/right direction key; also decrease/increase
◄/
parameter value of control bar.
select [Enter] / [Edit] operation
ENTER
Menu/ESC Enter into/exit Main menu
PIP display mode
PIP
Mute key
MUTE
Forward（x2、x4、x8）
FWD
Rewind（x2、x4、x8）
REW
Enter into record search, play record event
PLAY
Stop play / manual play
STOP
PAUSE/
Pause / play frame by frame
FRAME
（1/2、1/4、1/8）Slow play
SLOW
Zoom out video area
Z+
Zoom in video area
Z-
Extend focus
F+
Extend focus
F-
Increase PTZ brightness
I+
Decrease PTZ brightness
I-
Allow you set preset bit and control PTZ.
PTZ
Lock system
LOCK
4
Key Function
