- Page 1 User Manual...
-
Page 2: Table Of Contents
User Manual Contents CONTENTS ..................................1 SAFETY INSTRUCTION ..............................4 CHAPTER 1 FEATURES AND FUNCTIONS ........................1 CHAPTER 2: OVERVIEW ..............................2 2.1 8CH (1U) DVR F ..........................2 RONT ANEL RONT ANEL 2.2 8CH (1U) DVR R ............................. 3 ANEL ANEL 2.3 8CH R... - Page 3 User Manual 5.2.4.6 DDNS Set ....................................19 5.2.5 Alarm ..................................19 5.2.5.1 Motion ..................................... 19 5.2.5.2 Alarm Set ....................................20 5.2.6 Device ..................................21 5.2.6.1 HDD Set ....................................21 5.2.6.2 PTZ Set ..................................... 22 5.2.6.3 Serial Set ....................................22 5.2.7 System ..................................22 5.2.7.1 General ....................................
- Page 4 User Manual CHAPTER 7: APPENDIX ..............................39 7.1 O ..............................39 PERATION UNCTION ABLE 7.2 R ................................40 ECORD LARM SETTING 7.3 M ................................41 AIL BOX SERVER 7.4 T ................................. 41 ROUBLESHOOTING 7.5 U ................................42 SAGE AINTENANCE 7.6 S ..............................
-
Page 5: Safety Instruction
User Manual Safety Instruction 1. Read Instruction All the safety and operating instruction should be read before the equipment is operated. 2. Power sources This equipment should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power, please consult your equipment dealer. -
Page 6: Chapter 1 Features And Functions
User Manual Chapter 1 Features and Functions Function Brief and Description Double video output; with monitor, VGA virtual output port or HDMI Output; Real time Support net-viewer and MP live surveillance and also support zoom in/out, monitoring auto sequence and PIP display. H.264 video compression format;... -
Page 7: Chapter 2: Overview
User Manual Chapter 2: Overview Front Panel 8CH (1U) DVR Front Panel Reminder: DVR is the abbreviation of Digital Video Recorder Equipment. Key title Remar Item Function & Description Indicator If the “Green” indicator is on the system is getting Power Indicator power normally. -
Page 8: 8Ch (1U) Dvr Rear Panel Rear Panel
User Manual Rear Panel 8CH (1U) DVR Rear Panel Item Physical port Connection method Video input Connect CH1-4 (Virtual) video input device（BNC interface） Video output Connect monitor output(BNC interface) Audio Input 4CH audio input (RCA interface）; Audio Output Audio output (RCA interface）; USB Port Connect USB device (Flash Drive, Hard Drive and Recorder etc) USB Port... -
Page 9: 8Ch Remote Controller
User Manual 2.3 8CH Remote Controller Item Key title Key function Channel select 1-8; Numeric key Numeric key; Clicking numeric “0” allow you switch 9、0 to output device Multiple display mode Menu Enter into Main menu/Exit ▲ Up arrow key, Volume adjust ▼... -
Page 10: Chapter 3 Dvr Connection
User Manual Chapter 3 DVR CONNECTION 3.1 HDD Installation Caution： ： ： ： Please do not Install or take out hard drive when DVR is running! HDD Installation:： (1) Cut power firstly, and then remove screws and open DVR upper cover carefully; (2) Insert Power Cord and data cable into Pin of hard drive securely;... -
Page 11: Live Interface
User Manual 4.2 Live Interface After finishing initialization the system will enter into <Live> screen. Picture 4-2 is the 16-split display defaulted by system, which is showing no video input status. Once there are video inputs, the screen will display live images from the cameras. -
Page 12: Main Menu Guide
User Manual 5.1 Main Menu Guide Live set Display Output Set Privacy Zone Record Parameters Record Schedule Main Stream Record Search Clip Set Record Playback Search Backup Event Search Log search Network Set Sub stream Main Menu Email Set Network Mobile Set DDNS Set Motion Detection... -
Page 13: Main Menu
User Manual 5.2 Main Menu On <Live> mode, click [Menu] button on the front panel or Remote controller to enter into Main menu interface shown as Picture 5-2. And also you can click [ ] icon to enter the main menu screen. - Page 14 User Manual Click [Live] to pop up the interface Go to [Main menu Display Output] shown as Picture 5-6. Now you could to enter into the output set interface perform channel sequence setting. shown as Picture 5-5. Picture 5-5 Picture 5-6 Click [Spot output] option and set Click [Spot sequence] to enter into the relative parameters shown as Picture...
-
Page 15: Privacy Zone
User Manual 5.2.1.3 Privacy Zone The function Allow you setup privacy zone parameters according to Picture 5-12. Each channel could set up to four privacy zones, and please follow below steps to set: 1. Select the area no (Area 1 ~ Area 4); 2. -
Page 16: Main Stream
User Manual After you complete the schedule you activate it by clicking the After you complete the schedule you activate it by clicking the [Apply] button. You can also click on the Default button to use the system defaults. You can also click on the Default button to use the system defaults. Explanation: Under the <record>... -
Page 17: Channel Select
User Manual 5.2.3.2 Channel Select Then tick-select the channel you want to playback; select the channel you want to playback; Click [Main Menu Search Record search] Record search] and click [Play] button to enter into the playback and click [Play] button to enter into the playback to enter into the interface shown as Picture to enter into the interface shown as Picture mode shown as Picture 5... -
Page 18: Event Search
User Manual Record Clip and backup function and Zoo Record Clip and backup function and Zoom in/out function Picture 5-19B 19B-1 Picture 5-19C Clip and backup: When one channel is playing Clip and backup: When one channel is playing-back, the [ ] icon will appear in the [Play control] bar will appear in the [Play control] bar shown as Picture 5-19A-3. -
Page 19: Back-Up File Based On Time
User Manual Select DVD as backup In the [File List] mode, if you Select USB as backup device device and click [Apply] button, wish to backup records, please and click [Apply] button, and and then enter into the window tick-select the BAK check-boxes then enter into the window shown as Picture 5-23. - Page 20 User Manual Picture 5-25 Picture 5 Picture 5-26 Play button: click the icon to Play button: click the icon to playback the backup record; ： Pause button: click the icon to pause the backup record; Pause button: click the icon to pause the backup record; ：...
-
Page 21: Log Search
User Manual 5.2.3.6 Log Search Herein allow you preview the log information you Go to [Main menu Search Log] option to have searched. And click [Backup] to export all enter into the Log search interface shown as the log information which is listed. For other Picture 5-28. -
Page 22: Router's Port Forwarding
User Manual Friendly Reminder: All the parameters you set are available only when you click [Apply] and after system are restarted. User need to change MAC address when there are multiple DVRs at the same local area network. Details please refer to section 5.6.2.5 -System Information. When selecting Static from the Type, user can directly input IP address, Subnet Mask, Gateway and DNS shown as below picture 5-33. -
Page 23: Sub Stream
User Manual Friendly Reminder: The router’s port forwarding interface may be different, however, when entering into virtual server, user will always need forward port (range: 1025~65535) of router to IP address of DVR allocated or automatically captured, and select [All] or [Both] in corresponding protocol column and save the above setting. -
Page 24: Mobile Set
User Manual 5.2.4.5 Mobile Set The DVR is currently compatible with mobile phones running Andriod, Windows Mobile, Symbian operating systems, Iphone and Black berry on 3G networks. Click [Main menu Network Mobile] to enter into the [Mobile] interface shown as Picture 5-40. User Name: indicate user name of DVR, and support numbers and characters and 1~15 bits length User password: indicate user password of DVR, and also... -
Page 25: Alarm Set
User Manual Latch time: you can set how long the buzzer will sound when object move is detected (10s, 30s, 40s, 60s); Show Message: You can set show message on the screen when motion alarm is detected. Buzzer time: you can set how long the buzzer will sound when motion is detected (off, 10s, 30s, 40s, 60s);... -
Page 26: Device
User Manual Post Recording: you can set how long alarm record will last when alarm ends (30s, 1minute，2minutes， 5minutes); Copy: allow you copy all the setting of one channel to other ones. Alarm Type Function Sends alarm when DVR can’t receive video signal (such as camera damage, cable broken or Video Loss damaged or power supply malfunction). -
Page 27: Ptz Set
User Manual 5.2.6.2 PTZ Set Click [Main Menu Device PTZ] to enter into the below window shown as Picture 5-47. You could select the channel you desire to control and set PTZ protocol (Pelco-D or Pelco-P), Baud Rate (1200, 2400, 4800, 9600), Data bit (8, 7, 6, 5), Stop bit (1, 2), Parity Check (None, Odd, Even, Mark, Space), Address Code and Cruise status respectively. -
Page 28: Users
User Manual Picture 5-51 Picture 5-5 0 Note: The above [NTP function] change will be available only when system connected to internet. And When NTP function is set to “Enable”, system will calibrate the time at every 00:07:50 and every start-up. 5.2.7.2 Users Click [Main Menu System users] option and then enter into the interface shown as Picture 5-51 Picture 5-53... -
Page 29: Information
User Manual 5.2.7.3 Information Click [Main Menu System Info] and then enter into the interface shown as Picture 5 Info] and then enter into the interface shown as Picture 5 Info] and then enter into the interface shown as Picture 5-55. Now user can check the current Device check the current Device name, Device ID, Device type, Device S/N, MAC... -
Page 30: Menu Lock
User Manual 5.3 Menu Lock Considering a system safety feature you can click [ ] icon to lock system interface when leaving the DVR. If you want to login to the DVR again, you would input device code and password to unlock the interface shown as Picture 5-59 Friendly Reminder: Administrator has full authority over Main Menu operations and has an authority to... -
Page 31: Pip Mode
User Manual 5.6 PIP Mode You can display a Picture-in-Picture in live mode. PIP has two display modes, including 1X1 display mode and 1X2 display mode. 1x1 display mode 1x2 display mode 5.7Record search You could enter into [Record Search] menu from Pop-up menu conveniently and quickly and search/playback the record histories. -
Page 32: Chapter 6: Web Application Manager
User Manual Chapter 6: Web Application Manager 6.1 ActiveX control download and installation Open your web browser and input the IP address and web port of DVR, such as ： http://172.18.6.202:8080/ . If your computer is connected to internet, it will download and install “ActiveX” Plug-in automatically. -
Page 33: Web Application Manager Log - In
User Manual 6.2 Web Application Manager Log Web Application Manager Log-in After ActiveX controls installation ActiveX controls installation, please input user name, password and client port; and client port; and select <Main stream> or <sub stream>, and then allow you tick stream>... -
Page 34: Ptz Control
User Manual Or click the right key of mouse on each <Live> window to pop up the interface shown as Picture 6 mouse on each <Live> window to pop up the interface shown as Picture 6 mouse on each <Live> window to pop up the interface shown as Picture 6-4. Show bit rate: show current bit rate;... -
Page 35: Playback
User Manual 6.3.2 Playback Click [ ] icon to enter into <playback> interface ] icon to enter into <playback> interface shown Picture 6-7. Picture 6-7 6.3.2.1 Record search Firstly, select one day you want to check and tick Firstly, select one day you want to check and tick-select <synchronous Playback> and the channels you select <synchronous Playback>... -
Page 36: Playback Control
User Manual If you tick-select < > option, that means the selected channel will playback synchronously; > option, that means the selected channel will playback synchronously; otherwise, you could separately control the channels playback. otherwise, you could separately control the channels playback. Thirdly, Click [ ] icon to start record playback. -
Page 37: Configuration
User Manual Record file download Click [ ] icon to enter into the below interface shown as Picture 6 ] icon to enter into the below interface shown as Picture 6-12. Picture 6-12 Tick-select the record file you want to download and click [Start download] select the record file you want to download and click [Start download] System will download the record file in turn and save to local PC. -
Page 38: Record
User Manual 6.3.3.2 Record Click <Record> option to unfold its sub Click <Record> option to unfold its sub-options: Record parameter, Schedule and Main stream. options: Record parameter, Schedule and Main stream. Picture 6-15 Picture 6 Picture 6-16 1、 Record Parameters: Record Parameters: Under [Record parameters] option, allow you set channel, record enable, pack time you set channel, record enable, pack time... - Page 39 User Manual 2、Sub stream (shown as Picture 6 (shown as Picture 6-21): Relative parameters should be consistent with DVR local setting. 21): Relative parameters should be consistent with DVR local setting. Picture 6-21 3、 Email setting: Click [Email setting] option to allow you set alarm email configuration parameters shown Click [Email setting] option to allow you set alarm email configuration parameters shown Click [Email setting] option to allow you set alarm email configuration parameters shown as Picture 6-22.
-
Page 40: Alarm Set
User Manual 6.3.3.4 Alarm Set Click <Alarm> option to unfold its sub Click <Alarm> option to unfold its sub-options: Motion, I/O Alarm shown as Picture 6 options: Motion, I/O Alarm shown as Picture 6-25. Picture 6-25 1、 Motion Detection: allow you allow you configure its <Sensitivity>, <Alarm out>, <Alarm record>... -
Page 41: System
User Manual 2、PTZ: Configuration (shown as Picture 6 Configuration (shown as Picture 6-29): Details setting should be consistent with DVR local setting. 29): Details setting should be consistent with DVR local setting. Picture 6-29 6.3.3.6 System Click <System> option to unfold its sub Click <System>... -
Page 42: Advanced
User Manual 6.3.3.7 Advanced Click <Advance> to unfold its sub-options: System update, Load default, Events and system maintain etc. options: System update, Load default, Events and system maintain etc. 1、 、 、 、 Click <Advance> to unfold its System update: allow you upgrade DVR system remotely shown as Picture 6 System update: allow you upgrade DVR system remotely shown as Picture 6- -33. -
Page 43: Local Setting
User Manual 3、 、 、 、 Events: Allow you configure abnormal type, buzzer output time, and alarm email and show message shown Allow you configure abnormal type, buzzer output time, and alarm email and show message shown Allow you configure abnormal type, buzzer output time, and alarm email and show message shown as Picture 6-37. -
Page 44: Chapter 7: Appendix
User Manual Chapter 7: Appendix 7.1 Operation Function Table Type Title Description Page Time setting Set system date/time, display format and day-light saving time Set system language Language select Set CH title and position; adjust image color parameter Channel value; set CH display to ON / Off and time display/recording setting time overlaying to On/Off. -
Page 45: Record Alarm Setting
User Manual Remote Check local record history via network playback PTZ control Remotely control PTZ camera, position, focus, zoom and iris etc. parameter Set local CH display, record, alarm, PTZ control set of DVR parameter value via network remotely Backup record file via network Network download Check device ID, software version and MAC... -
Page 46: Mail Box Server List
User Manual 7.3 Mail box server List Web site Sender server（ （ （ （ 25） ） ） ） Receiver server（ （ （ （ 110） ） ） ） Mail box @163.com smtp.163.com pop3.163.com @vip.163.com smtp.vip.163.com pop.vip.163.com @188.com smtp.188.com pop.188.com www.163.com @126.com smtp.126.com pop3.126.com @netease.com... -
Page 47: Usage Maintenance
User Manual Q: “Record” Can not work normally, how to deal with? A: Check if the current screen is in Play mode, pressing [Stop] button to exit the Play mode and then you can enter into the [Record] function. Q: Why the Remote Controller can’t work normally? A: Check if the battery is power off;... -
Page 48: System Connection Diagram
User Manual 7.6 System Connection Diagram System Connection Diagram 7.7 Accessories 8 CH Accessories Power Adapter User Manual USB Mouse USB Mouse Remote Controller Software CDSoftware CD... - Page 49 The material in this document is the intellectual property of our department . No part of this manual reproduced, copied, translated, transmitted, or published in any form or by any means without our department prior written permission. Our products are under continual improvement and we reserve the right to make changes without notice.
