2.2 Side Panel
Please refer to the following interface for side panel dimension information. The unit is mm. See
Figure 2-2.
2.3 Front Panel
Please refer to the following interface for the front panel information. The unit is mm. See Figure
2-3.
eLineTechnology.com
GND
Figure 2-2
Please make sure the
device is securely
earthed to prevent the
thunderstorm strike.
17
