3.1.3 Remove Lens

Please follow the steps listed below to remove lens. The interface is shown as in Figure 3-3.
Turn the lens counter clockwise and then remove it from the camera.
Unplug the auto lens cable socket from the auto lens connector. If you are using the manual
aperture lens, please skip to the following step.
If there is no lens, please put the CCD protection cap back to protect the CCD.

3.2 SD Card

3.2.1 Installation

Please follow the steps listed below to install SD card. The interface is shown as in Figure 3-4
and Figure 3-5.
Use the screwdriver to loosen the SD card protection screw in the rear panel, and then
remove the SD card protection cap from the camera.
Install the SD card to the camera according to the proper installation position.
Put the SD card protection cap back.
Use the screwdriver to fix the SD card protection cap screw firmly to secure the SD card
protection cap in the camera.
eLineTechnology.com
Figure 3-2
Figure 3-3
