Remove - Dahua IPC-HF3500 Series User Manual

Use the screwdriver to loosen the 3G card protection cap screw in the side panel, and then
remove the 3G card protection cap from the camera.
Install the 3G card to the camera according to the proper installation position.
Put the 3G card protection cap back.
Use the screwdriver to fix the 3G card protection cap screw firmly to secure the 3G card
protection cap.

3.3.2 Remove

Please follow the steps listed below to remove 3G card. The interface is shown as Figure 3-9.
Use the screwdriver to loosen the screw of 3G card protection cap in the rear panel.
Remove the cap from the camera.
Follow the 3G card direction to remove the 3G card.
Insert the 3G card protection cap.
Use the screwdriver to fix the screw to secure the protection cap.
eLineTechnology.com
Figure 3-7
Figure 3-8
Figure 3-9
24
