Tera Gear Weekend Warrior GSF3916 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
WARNING:
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
GSF3916
Owner's Manual
Weekend Warrior LP Gas Grill
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, PLEASE CALL 1-877-630-5396
(TOLL-FREE), 10:00 A.M. – 19:00 P.M. (EST), MONDAY-FRIDAY.
Service Center: 1-877-630-5396
0
TG 1201 2509
NG 192581

Advertisement

Table of Contents
loading

Related Manuals for Tera Gear Weekend Warrior GSF3916

Summary of Contents for Tera Gear Weekend Warrior GSF3916

  • Page 1 TG 1201 2509 NG 192581 Weekend Warrior LP Gas Grill WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. DANGER: Failure to follow these instructions could result in fire or explosion that could cause property damage,...

  • Page 2: Grill Operation

    Grill Operation 1-2-3 Before Grilling Step 1 Keep your grill a safe distance away from your property. Step 2 Always perform a leak test on all connections and hoses. Step 3 Keep children away from the grill. During Grilling (To avoid tripping safety valves, please follow these instructions carefully!) Step 1 First open lid and turn gas tank on slowly.

  • Page 3: Table Of Contents

    Table of Contents For Your Safety ........................ 2 Package Contents ......................5 Hardware Contents ......................6 Assembly Instructions..................... 7 Operating Your Grill....................... 11 Connecting & Disconnecting The Gas Cylinder............12 Checking for Leaks......................12 Lighting Your Grill......................12 Excess Flow Safety Valve Reset Procedure ............... 14 Care and Maintenance ....................
  • Page 4 WARNING: This grill is for outside use only. It should not be used in a building, garage or any other enclosed area. The use of alcohol, prescription or non-prescription drugs may impair an individual’s ability to properly assemble or safely operate this appliance.

  • Page 5: General Information

    Never attempt to move this grill while it is in operation or while it is still hot to prevent possible personal injury. Never store or use gasoline or other flammable or volatile substances in the vicinity of this grill or in the vicinity of any other heat-generating appliance because of the danger of starting a fire.

  • Page 6: Package Contents

    Package Contents Part Description Part Description Part Description Body assembly Tool hanger Right side panel Warming rack Side burner assembly Left side panel Grease tray Right side shelf Heat insulator Cooking grid(L) 2PCS Side burner knob seat Cart front panel 2PCS Cooking grid(S) Side burner knob...

  • Page 7: Hardware Contents

    Hardware List Spanner Hardware listed above is not scaled to exact size. (A screwdriver is required for assembly and is included for your convenience). GSF3916 Owner’s Manual...

  • Page 8: Assembly Instructions

    Assembly Instructions Remove all contents from the carton packaging. Make sure all parts are present before attempting assembly. Once the grill is fully assembled, go back and check to make certain all the bolts are secure. Tighten again using the screwdriver provided if necessary.
  • Page 9 Step 4 (Cart fill panel assembly) a) Align each hole on the cart front panel (V) with the holes on the upper front beam (P) and cart base panel (R), then insert one bolt (AA), one spring washer (CC) and one flat washer (DD) into the holes and tighten by hand until secure.
  • Page 10 Step 8 (Side bar tool hanger assembly) a) Turn over the left side shelf (I), and then align the holes on the end of the side bar tool hanger (J) with the holes on the left side shelf. b) Insert one bolt (AA), one spring washer (CC) and one flat washer (DD) into each hole.
  • Page 11 Step 11 (Assemble the heating plate, cooking grid andwarming grid ) a) Place the heating plate (F) on inside the firebox upon the burners. b) Place the cooking grate (D & E) and into firebox upon the heating plate. Insert the four feet of the warming rack (B) into the holes on the side wall of firebox.

  • Page 12: Operating Your Grill

    Fully Assembled View Right side Left side Operating Your Grill CAUTION: Use only the regulator provided. If a replacement is necessary, call our customer service center. The use of unauthorized parts can create an unsafe condition and environment. The propane gas supply cylinder used must be constructed and marked in accordance with local codes, with either the Natural Fuel Gas Code, ANSI Z223.

  • Page 13: Connecting & Disconnecting The Gas Cylinder

    Connecting & Disconnecting The Gas Cylinder LP (Propane) Gas Supply Connection & Disconnecting 1. Always place the propane cylinder on the tank holder under the cart. 2. Always confirm that all burner control knobs are in the OFF position before activating the gas supply. 3.
  • Page 14 Turn WARNING: Attempting to light the burner with the lid closed may cause an explosion. Make sure there are no obstructions of airflow to the gas unit. Spiders and insects can nest and clog the burner/venturi tube at the orifice. A clogged burner tube Push can lead to a fire beneath the appliance.

  • Page 15: Excess Flow Safety Valve Reset Procedure

    Confirm that the burner is properly lit and that the flame pattern is as desired (see fig. A, B and C below for the proper flame patterns). If the flame pattern is other than normal, consult the Troubleshooting on page 20 for corrective action. FIG.

  • Page 16: Care And Maintenance

    Re-connect the regulator to the LP tank. Slowly turn the LP tank valve ¼ turn at a time and have the valve all the way open. With the lid open: For grill with ignition button: turn on only ONE burner control knob to the HIGH position. Ignite the grill by pushing the ignition button.

  • Page 17: Troubleshooting

    Grease Cup – Periodically empty the grease cup and clean with a dishwashing detergent and hot water solution. Cleaning the Burner Assembly Turn gas off at the control knobs and propane tank. Remove cooking grates and heat plate. Remove grease cup. Remove burner by unscrewing nut from beneath burner “foot”...
  • Page 18 New burner may have residual Burn grill for 15 minutes with the lid Flame is yellow or orange. manufacturing oils. closed. Spider webs or insect nest in Clean venturi. venturi. Food residue, grease or seasoning Clean burner. salt on burner. Poor alignment of valve to burner Assure burner venturi is properly venturi.

  • Page 19: Waranty Program

    Warranty Program Proof of purchase is required to access this warranty program, which is in effect from the date of purchase. If unable to provide proof of purchase or after the warranty has expired, customers will be subject to parts, shipping and handling fees. Full 30-Day Warranty Any missing parts can be replaced at no charge within 30 days from the date of purchase with a valid proof of purchase.
