WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
WARNING:
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
GSS3220A
Instruction Manual
Propane gas barbecue
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. IF
YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE, GIVE
THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, PLEASE CALL 1-877-630-5396
(TOLL-FREE), 10:00 A.M. – 19:00 P.M. (EST), MONDAY-FRIDAY.
Service Center: 1-877-630-5396
0
TG 1201 2560
NG 993066
Advertisement
Table of Contents
Related Manuals for Tera Gear TG 1201 2560
Summary of Contents for Tera Gear TG 1201 2560
- Page 1 TG 1201 2560 NG 993066 Propane gas barbecue WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. DANGER: Failure to follow these...
-
Page 2: Grill Operation
Grill Operation 1-2-3 Before Grilling Step 1 Keep your grill a safe distance away from your property. Step 2 Always perform a Leak Test on all connections and hoses. Step 3 Keep children away from the grill. During Grilling (To avoid tripping safety valves, please follow these instructions carefully!) Step 1 First open lid and turn gas tank on slowly. -
Page 3: Table Of Contents
Table of Contents For Your Safety ........................ 2 Package Contents ......................5 Hardware Contents ......................6 Assembly Instructions..................... 7 Operating Your Grill....................... 14 Connecting Gas Cylinder ....................14 Checking for Leaks......................15 Lighting Your Grill......................15 Excess flow safety valve reset procedure ..............17 Care and Maintenance .................... - Page 4 WARNING: This grill is for outside use only. It should not be used in a building, garage or any other enclosed area. The use of alcohol, prescription or non-prescription drugs may impair an individual’s ability to properly assemble or safely operate this appliance. Always open the grill lid carefully and slowly as heat and steam trapped within the grill could cause severe burns.
-
Page 5: General Information
might otherwise be sufficient to ignite nearby combustible or volatile substances. Always locate this grill where there will be ample combustion and ventilation air, but never position it in the direct path of a strong wind. Never allow the grill to operate while unattended to prevent uncontrolled grease fires from erupting. -
Page 6: Package Contents
Package Contents Part Description Part Description Part Description Cart bottom 1 PC Body assembly 1 PC Heat insulator panel 1 PC Door magnet Left side shelf Grease pan 1 PC 1 PC 1 PC Cart left side panel 1 PC Right side shelf 1 PC Cart right side panel... -
Page 7: Hardware Contents
Hardware Contents AA: 21 PCS BB: 6 PCS CC: 19 PCS M6 x 15 Bolt M4 x 10 Bolt M6 Flat Washer DD: 15 PCS EE: 6 PCS FF: 4 PCS M4 Lock Washer M4 Flat Washer M6 Lock Washer GG :4 PCS HH: 1 PC Screwdriver... -
Page 8: Assembly Instructions
Assembly Instructions Remove all contents from the carton packaging. Make sure all parts are present before attempting assembly. Once the grill is fully assembled, go back and check to make certain all the bolts are secure. Tighten again using the screwdriver provided if necessary. - Page 9 Step 4 (Assemble the front beam to the cart) a) Place the front beam (F) on the two cart side panels. b) Align the two holes on the right end of front beam (F) with the top & side two holes on the frame of cart right side panel.
- Page 10 Step 7 (Basket support assembly) a) Align the four holes on the track of the basket support (I) with the four holes on the cart bottom. b) Insert one bolt (AA), one spring washer (DD) and one flat washer (CC) into each hole. Go back and tighten all bolts using the screwdriver provided.
- Page 11 Step 10 (Assemble the body to the cart) a) Put the body assembly (L) on the top of cart assembly. b) Align the two holes on the top of cart right side panel with the two holes on the right of body assembly. Insert one bolt (AA) with one spring washer (DD) and one flat washer (CC) into each pre-drilled hole.
- Page 12 Step 13 (Side burner assembly) a) Open the side burner lid and place the right side burner assembly (Q) onto the right side shelf. Make certain the venturi tube is connected properly with valve. b) Align the four holes on the right side burner assembly (Q) with the four holes on the right side shelf.
- Page 13 Step 15 (Heat plate, cooking grid and warming rack assembly) a) Place the heat plates (R) onto the heat plate support. b) Place the cooking grids (S) upon the heat plates. Place the warming rack (T) on the warming grid support as shown.
- Page 14 Step 18 (Grease cup assembly) a) Put the grease cup (V) into the grease cup support (U). Hang the cup support on the grease pan. b) Pull in the grease pan by moving it through the guide track under the body assembly.
-
Page 15: Operating Your Grill
Operating Your Grill CAUTION: Use only the regulator provided. If a replacement is necessary, call our customer service center. The use of unauthorized parts can create an unsafe condition and environment. The propane gas supply cylinder used must be constructed and marked in accordance with local codes, with either the Natural Fuel Gas Code, ANSI Z223. -
Page 16: Checking For Leaks
To prevent fire or explosion hazard when testing for a leak: Always perform the “leak test“ before lighting the grill and each time the cylinder is connected for use. Do not smoke or allow other sources of ignition in the area while conducting a leak test. Conduct the leak test outdoors in a well-ventilated area. - Page 17 2. If the burner flame goes out during operation, immediately turn the gas “OFF”. Open lid to let the gas clear for at least 5 minutes before re-lighting. 3. Before cooking on the grill for the first time and operate the grill for approximately 15 minutes with the lid closed and the gas turned on “HIGH”.
-
Page 18: Excess Flow Safety Valve Reset Procedure
Burner installation and adjustment 1. Release the screw on venturi tube. 1. Overlap 14 mm between 1. Hook should face upwards. 2. Adjust the flame by turning the collar venturi tube and nozzle on head of venturi tube from back side when assembling. -
Page 19: Care And Maintenance
Turn all burner control knobs to the OFF position. Disconnect the regulator from the LP tank. Open the lid of the grill. Turn burner control knobs to HIGH. Wait at least 1 minute. Turn burner control knobs OFF. Wait for at least 5 minutes. Re-connect the regulator to the LP tank. -
Page 20: Troubleshooting
DO NOT use cleaners that contain acid, mineral spirits or xylene. Outside surfaces Use a mild dishwashing detergent and hot water solution to clean. Rinse thoroughly with water. Inside surface If the inside surface of the grill lid has the appearance of peeling paint, baked on grease has turned to carbon and is flaking off. - Page 21 Excess flow safety device Refer to the Excessive flow safety Sudden drop in gas flow or reduced may have been activated. valve reset procedure on page 17. flame height. Irregular flame pattern, flame does not Burner ports are clogged or blocked. Clean burner ports.
-
Page 22: Warranty Program
Warranty Program Proof of purchase is required to access this warranty program, which is in effect from the date of purchase. If unable to provide proof of purchase or after the warranty has expired, customers will be subject to parts, shipping and handling fees.
