Tera Gear GSF2818A Manual

Ter 75k btu 4+1+1 pro gas grill

Advertisement

WARNING
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property
damage.
Read the installation, operation
and maintenance instructions
thoroughly before installing or
servicing this equipment.
DANGER
Failure to follow these
instructions could result in fire
or explosion that could cause
property damage, personal
injury or death.
DANGER
DO NOT use gas grill for indoor
cooking or heating. TOXIC fumes
can accumulate and cause
asphyxiation. DO NOT use in or
on boats or recreational vehicles.
WARNING
FOR YOUR SAFETY:
For Outdoor Use Only
(Outside any enclosure)
Model Number: GSF2818A (1501 2018)
TER 75K BTU 4+1+1 Pro Gas Grill
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE
ELSE, GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR
FUTURE REFERENCE.
FOR CUSTOMER SERVICE:
CALL 1-877-630-5396 (TOLL-FREE)
10:00 A.M. – 7:00 P.M. (EST), MONDAY-FRIDAY
- 1 -

Advertisement

Table of Contents
loading

Summary of Contents for Tera Gear GSF2818A

  • Page 1 Model Number: GSF2818A (1501 2018) TER 75K BTU 4+1+1 Pro Gas Grill WARNING Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment.
  • Page 2 Grill Operation 1‐2‐3 Before Grilling Step 1 Keep your grill a safe distance away from buildings.* Step 2 Always perform a Leak Test on all connections and hoses. * Step 3 Keep children away from the grill. During Grilling (To avoid tripping safety valves, please follow these instructions carefully!) Step 1 Open the lid and turn the gas tank on slowly.
  • Page 3: Table Of Contents

    Table of Contents For Your Safety........................4 Illustrated Parts List ......................6 Hardware List.........................7 Assembly Instructions……………………..................8 Operating Your Grill......................1 3 Connecting & Disconnecting Gas Cylinder................13 Checking for Leaks........................14 Lighting Your Grill........................15 Excess flow safety valve reset procedure................17 Care and Maintenance..................
  • Page 4: For Your Safety

    For Your Safety Dear Valued Customer, Congratulations on your new barbecue grill purchase! You’ve made the right choice. In this manual, you will find assembly instructions, suggestions for grilling and helpful hints, as well as guidelines for the safe operation, proper care and use of your grill.
  • Page 5: General Information

    Safe Locations for Use of This Outdoor Grill CAUTION Never use this outdoor grill inside any building, garage, shed or breezeway, or inside any boat, trailer or recreational vehicle to prevent a possible fire and to prevent the possibility of carbon monoxide poisoning or asphyxiation. WARNING ●...
  • Page 6: Illustrated Parts List

    Illustrated Parts List Part Description Part Description Part Description Warming Rack Right Side Shelf Cart Base 1 pc Cooking Grid 2PCS Right Side Shelf Decorative Tank Clip 1 pc Sheet Lava Heat Plate 3PCS Side Burner Grid Caster 4PCS Heat Plate Sear Burner Door Beam Body Assembly...
  • Page 7: Hardware List

    Hardware List AAA:24PCS BBB:24PCS CCC:24PCS M6*15 bolt M6 spring washer M6 flat washer DDD:6PCS EEE:6PCS FFF:6PCS M4*12 bolt M4 spring washer M4 flat washer GGG:1PC HHH:4PCS III:1PC Battery Screwdriver Retaining pin JJJ:1PC (M10)Spanner Hardware listed above is not scaled to exact size. (A screwdriver is required for assembly and is included for your convenience).
  • Page 8: Assembly Instructions

    Assembly Instructions Remove all contents from the carton packaging. Make sure all parts are present before attempting assembly. Once the grill is fully assembled, go back and check to make certain all the bolts are secure. Tighten again using the screwdriver provided if necessary.
  • Page 9 Step 4 a) Insert the tank clip (T) into the two holes on the cart base. Step 5 a) Align the door handle (AA) and the handle seats (Z) with the two holes on the left door (X). Insert one bolt (AAA), one spring washer (BBB) and one flat washer (CCC) into each hole.
  • Page 10 Step 8 a) Align the five holes on the left decorative sheet (I) with the five holes on the left side shelf (H) and insert one bolt (AAA) with one spring washer (BBB) and one flat washer (CCC) into each pre‐drilled hole. Tighten bolts by hands until secure.
  • Page 11 Step 11 a) Connect the venture tube and side valve nozzle, and insert the retaining pin (GGG) into place. b) Connect the side burner ignition cable by inserting it onto the electrode. Make certain the connection is secure. Step 12 Insert the grease pan (F) under the grill body and hook up the grease cup (G) under the grease pan.
  • Page 12 Step 14 a) Put the gas tank on the tank holder. Secure the tank with the tank clip. Step 15 a) Connect the upper cable with the cable of the battery case. b) Open the lid of the battery case, and put three batteries (HHH) into the case in correct negative and positive ends as the figure shown.
  • Page 13: Connecting & Disconnecting Gas Cylinder

    Fully Assembled View Operating the Grill CAUTION Use only the regulator provided. If a replacement is necessary, call the customer service center. The use of unauthorized parts can create an unsafe condition and environment. The liquid propane gas (LP‐gas) supply tank(s) to be used must be: a) Constructed and marked in accordance with the specifications for LP gas tanks of the National Standard of the Transportation of Dangerous Goods Commission of Canada for Tanks, Spheres and Tubes (CAN/CSA‐B139), as applicable;...
  • Page 14: Checking For Leaks

    Before connecting, make sure there is no debris caught in the head of the gas tank, regulator valve or in the head of the burner and burner ports. Connect regulator valve and hand tighten firmly. DO NOT obstruct the flow of combustion air or ventilation air to the grill.
  • Page 15: Lighting Your Grill

    Make sure control knobs are in the “OFF” position. Spray some solution on the tank valve up to the regulator connection. (See diagram to right.) Inspect the solution at the connections for bubbles. If no bubbles appear, the connection is secure and the leak test is finished.
  • Page 16 Open the lid while lighting the burner. The lid must remain open while the burner is lit. 2. The burner valve knob must be in the “OFF” position. 3. Open the tank valve. 4. Push the side burner knob fully and rotate it slowly about 1/4 turn counterclockwise, and then press the igniter promptly.
  • Page 17: Excess Flow Safety Valve Reset Procedure

    Flare‐Ups “Flare‐ups” sometimes occur when food drippings fall onto the hot heat distribution plate or burners and ignite. Some flaring is normal and desirable as it helps impart the unique flavors associated with grilled foods. Controlling the intensity of the flare‐ups is necessary, however, in order to avoid burned or unevenly cooked foods and to prevent the possibility of accidental fire.
  • Page 18: Care And Maintenance

    Care and Maintenance IMPORTANT Always allow the grill to completely cool off before covering the grill to prevent corrosion from condensation. CAUTION All cleaning and maintenance should be done when the grill is cool, with the fuel supply turned off at the control dial and the propane tank disconnected.
  • Page 19: Troubleshooting

    TROUBLESHOOTING Problem Possible cause Prevention/Cure Burner will not light using knobs or Wires or electrode is covered by Clean wire or electrode using a igniter cooking residue cloth and rubbing alcohol Electrode and burners are wet Wipe with dry cloth Ignition electrode cracked or Replace electrode broken;...
  • Page 20 Flare‐up Grease buildup Clean grill Excessive fat in meat Trim fat from meat before grilling Excessive cooking temperature Adjust (lower) temperature Persistent grease fire Grease trapped between burner Turn knobs to OFF. Turn gas OFF at and food on the grate propane tank.
  • Page 21: Warranty Program

    Warranty Program Proof of purchase is required to access this warranty program, which is in effect from the date of purchase. If unable to provide proof of purchase or after the warranty has expired, customers will be subject to parts, shipping and handling fees. Full 30‐Day Warranty Any missing parts can be replaced at no charge within 30 days from the date of purchase with a valid proof of purchase.
