NOTES
DO NOT Ground Balance at the
beach – leave GB disabled.
In highly mineralized ground it
may be necessary to repeat the
Ground Balance process.
If you are unable to successfully
Ground Balance, disable GB before
continuing.

Audio

ʯ Press from the Detect or Map
screens to display the last
adjusted Audio setting
ʯ Press and hold at any time
to display the Audio Quick
Menu
ʯ Press from the menu screens
to activate the RIGHT arrow
CTX 3030 Instruction Manual
Function Buttons

Enable Ground Balance

The Enable GB option toggles between on or off as indicated by the green tick
in the check box to the right of the option. By default, the Enable GB option is
selected when the menu opens, and the check box is empty indicating that Ground
Balance is off.
1. Press Select to confirm Enable GB selection.
A green tick will appear in the check box and Ground Balance is enabled.
2. Press Select again to remove the green tick and disable Ground Balance.

Perform Auto Ground Balance

Ground Balance must be enabled to perform Auto Ground Balance.
1. Find a metal free location near the area being detected. This may not be easy in a
cluttered environment.
2. With the Ground Balance Quick Menu displayed, use the down arrow button to
highlight the Start GB option and press Select.
A message will be displayed to confirm Ground Balance in progress.
3. Lift the coil to approximately 1 foot (30 cm) above the ground, then lower it again
until it almost touches the ground. Repeat this movement several times.
Audio will provide feedback during the GB process. The audio should quickly get
quieter and upon successful completion will be totally quiet.
A second message will advise you when the GB process is complete.
4. If a complete Ground Balance is not achieved, repeat steps 2 and 3.
Audio
Audio settings for the detector's internal speaker, headphones, wireless speaker and
wireless headphones are independently adjustable via the Audio menu. The audio
option used will be dictated by the current detector settings as shown in Table 18.
Audio Output
WM 10 Headphones
WM 10 Speaker
Detector Headphones
Detector Speaker
Table 18 – CTX 3030 audio options
The Audio function button gives you access to all Audio settings.
Detector Settings and Connections
Wireless enabled and connected + headphones connected
Wireless enabled and connected + headphones not connected.
Wireless not enabled + headphones connected.
Wireless not enabled + headphones not connected
22
