Open/Back View

No.
Names of Parts
1
Glass Surfaces
2
Separation Roller Assembly
3
Output Rollers
4
Pick Rollers
5
Guide Arms
6
Feed Roller Assembly
7
Power Switch
8
Power Connector
9
Hi-Speed USB Port
Functions of Parts
The places where the CCD cartridges are stored.
Used to separate each sheet of documents when a
stack of documents are fed into the feeder.
Used to eject documents after scanning.
Used to pick up documents into the feeder.
Slides to hold a stack of documents.
Used to feed documents into the feeder.
Turns the scanner on or off.
Connects the scanner to the power adapter.
Connects the Hi-Seed USB (USB 2.0) cable to the
computer.
