3. To remove the Separation Roller from the assembly unit, hold the roller and
then pull it out from the assembly unit.
4. To install a new Separation Roller onto the
assembly unit, insert the axes on both sides
of the roller into the slots of the assembly.
5. Insert and push the whole assembly back into its component until you hear a
"click".
Note:
•
The recommended replacement point for the Separation Roller is
approximately 30,000 scans through the feeder.
•
Please contact your local resellers for purchasing new Separation Roller.
Separation Roller
ArtixScan DI 3130c User's Manual
41
