MAINTENANCE

■ Fuse replacement

If a fuse blows or the repeater stops functioning,
try to fi nd the source of the problem, and replace
the damaged fuse with a new, rated fuse.
Replace the circuitry fuse as shown below.
"There are two fuses:
The left fuse, as pictured, is for repeater TX
The right fuse is for repeater RX" The right fuse is for repeater RX"
WARNING:
power cable and/or DC power cable from
the repeater. Otherwise, there is danger of
electric shock and/or equipment damage.
13
DISCONNECT the AC
