Summary of Contents for Icom CY-5300
- Page 1 INSTRUCTION MANUAL VHF FM REPEATER CY-5300 UHF FM REPEATER CY-6300...
-
Page 2: Explicit Definitions
AVOID using or placing the repeater in areas The Icom America Systems logo is a trademark with temperatures below –30°C (–22°F) or above of Icom, Inc. +60°C (+140°F). Be aware that temperatures on a vehicle’s dashboard can exceed 80°C... -
Page 3: Supplied Accessories
FORWARD SUPPLIED ACCESSORIES Thank you for purchasing this Icom America The following accessory is supplied with VHF/UHF repeater. CY FR series Systems CY FR With proper care, this product should provide you [AC120V version] years of trouble-free operation. ➀ AC power cable (OPC-510) ….....……… 1 ... -
Page 4: Panel Description
PANEL DESCRIPTION ■ Front Panel MICROPHONE CONNECTOR ➊ [MIC] Use Icom microphones only. Other manufacturer’s microphones have different pin assignments, and connection to the CY FR series may damage the repeater. ➀ +8 V DC output (Max. 15 mA) ➁ Output port for PC programming ➂... -
Page 5: Ground Terminal [Gnd]
PANEL DESCRIPTION ■ Rear Panel ➒ ➌ ➑ ➊ ➏ ➐ ➎ ➋ ➍ LIGHTED POWER SWITCH [POWER] GROUND TERMINAL [GND] ➊ ➏ Toggles to turn the repeater AC power ON Ground the repeater through this terminal or OFF. Located on the back panel of the to prevent electric shocks, TVI, BCI and other repeater. -
Page 6: Accessory Connector
PANEL DESCRIPTION ■ Accessory Connector Pin Name Description Specification No connection — Input terminal for serial communication data. — Output terminal for serial communication data. — Input terminal for request-to-send data. — Output terminal for clear-to-send data. — No connection —... -
Page 7: Installation And Connections
INSTALLATION AND CONNECTIONS ■ Unpacking ■ Duplexer After unpacking, immediately report any damage A duplexer is separately required when only to the delivering carrier or dealer. Keep the one antenna is used for both transmitting and shipping cartons. receiving. Select a duplexer according to the transmitting and receiving frequencies. -
Page 8: Required Connections
INSTALLATION AND CONNECTIONS Required Connections ■ [DC POWER INPUT TERMINAL] Make sure the back up battery is correctly connected. Use a cable with following current capacity. Solder or clamp the cable plug when connecting the power cable to the backup battery to prevent voltage drops. Power cable current capacity: 25 A or more [TX(TX•RX) ANT] [RX ANT]... - Page 9 INSTALLATION AND CONNECTIONS Power ■ In DC operation Make sure the AC [POWER] switch is turned OFF when connecting an AC power cable or a CAUTION: Voltages greater than 16 VDC backup battery (emergency power supply). will damage the repeater. Check the source voltage before connecting the power cable.
-
Page 10: Optional Unit Installation
OPTIONAL UNIT INSTALLATION ■ Opening the repeater’s case Follow the case and cover opening procedures CAUTION: Disconnect the AC power cable shown here when an optional unit is installed or and/or DC power cable from the repeater. adjustments are required to the internal units, etc. Otherwise, there is danger of electric shock and/or equipment damage. -
Page 11: Operation
OPERATION ■ Turning power ON ➀ On rear panel, toggle AC Power Switch up to turn AC power ON. ■ Receiving and transmitting Receiving ➀ When receiving a signal, RX indicator turns ON. No audio is output from the repeater. A subscriber unit will be required to hear the audio. -
Page 12: Maintenance
MAINTENANCE ■ Fuse replacement CAUTION If a fuse blows or the repeater stops functioning, DISCONNECT the DC power try to find the source of the problem, and replace cable from the repeater. Otherwise, there is the damaged fuse with a new, rated fuse. a danger of electric shock and/or equipment damage. -
Page 13: Specifications And Options
SPECIFICATIONS AND OPTIONS ■ Specifications (See UR Service Manual for module specifications) ◆ UR-FR5300 GENERAL Power supply 105-130 VAC 50/60 hz 5A Max requirement (nominal) 185-250 VAC 50/60 hz 13.6 VDC (nominal) 16.2 Amp Max Dimensions 480 (W) x 133 (H) x 364 (D) mm; (Projections not included) 18.90 (W) x 524 (H) x 14.33 (D) in. - Page 14 • HM-152T DTMF MICROPHONE Hand microphone with a DTMF keypad • SM-26 DESKTOP MICROPHONE • UX-241 GNSS ANTENNA • Various duplexers and preselectors are available in both VHF and UHF. Please contact Icom America Customer Service to find the currently available options.
- Page 15 MEMO...
- Page 16 Count on us! ©2021 Icom America Inc. The Icom logo is a registered trademark of Icom Inc. All specifications and information is subject to change without notice or obligation. All other trademarks remain the property of their respective owners. 42960...
