SPECIFICATIONS AND OPTIONS

■ Specifi cations
◆ CY-F121S
General
•Frequency coverage
•Channel spacing
•Number of channels
•Antenna connector
•Power supply voltage
(Negative ground)
•Current drain (apporx.)
•Operating temp. range
•Dimensions (Projections not included)
[25W]:
[50W]:
•Weight:
•RF output power:
(High/Low2/Low1)
•Modulation system:
•Max. frequency deviation: ±2.5 kHz
•Frequency Error:
•Spurious emission:
•Adjacent channel power:
•Audio frequency response: +2 dB to -8 dB of
•Audio harmonic distortion : 3% typical at 1 kHz , 40%
•FM Hum and noise:
(typical, with CCIT fi lter) 46 dB
•Limiting character of:
•Microphone connector:
: 136.000-174.000 MHz*
: 12.5/25 kHz (Narrow/Wide)
: Max 8 channels
: SO-293 (50Ω)
: 13.2 V DC nominal [25W]
13.6 V DC nominal [50W]
: TX (25W) 7.0 A
(50W) 13.0 A
Max. Audio 1.2 A
Stand-by 0.3 A
: -30 °C to +60 °C
(-22 °F to +140 °F)
480 (W) x 133 (H) x
364 (D) mm; 18.90 (W) x
5.24 (H) x 14.33 (D) inches
480 (W) x 133 (H) x
364 (D) mm; 18.90 (W) x
5.24 (H) x 14.33 (D) inches
8.6 kg; 18 lb [25W]
8.6 kg; 18 lb [50W]
25W/10W/2.5W [25W]
50W/25W/5W [50W]
Variable reactance freq.
modulation
[Narrow]
±5.0 kHz [Wide]
±5.0 ppm
70 dB typical
60 dB [Narrow]
70 dB [Wide]
6 dB/octave range from:
300 Hz to 2550 Hz [Narrow]
300 Hz to 3000 Hz [Wide]
deviation
40 dB [Narrow]
[Wide]
70-100% of max deviation
modulation
8-pin modular (600Ω)
Receiver
•Receive system:
•Intermediate frequency:
•Sensitivity:
•Squelch sensitivity:
•Adjacent channel:
Selectivity (typical)
•Spurious response:
•Intermodulation (typical):
•Hum and Noise (typical):
•Audio output power:
•External SP connector:
◆ CY-F221S
General
•Frequency coverage:
•Channel spacing:
•Number of channels:
•Antenna connector:
•Power supply voltage:
(negative ground)
•Current drain (apporx.):
•Operating temp. range:
•Dimensions (Projections not included)
[25W]:
[45W]:
•Weight:
Transmitter
•RF output power:
(High/Low2/Low1)
Double-conversion
superheterodyne system
1 : 46.35 MHz, 2 : 450 kHz
st nd
0.25 µV at 12 dB SINAD
0.25 µV
65 dB [Narrow]
75 dB [Wide]
75 dB
74 dB
40 dB [Narrow]
45 dB [Wide]
4W typical at 10% distortion
with a 4Ω load
2-conductor 3.5 (d) mm
( / / ")/4Ω /
1
8 8
400.000-430.000 MHz*
440.000-490.000 MHz*
12.5/25 kHz (Narrow/Wide)
Max 8 channels
SO-293 (50Ω)
13.6 V DC nominal
TX (25W) 7.0 A
(45W) 13.0 A
Max. Audio 1.2 A
Stand-by 0.3 A
-30 °C to +60 °C
(-22 °F to +140 °F)
480 (W) x 133 (H) x
364 (D) mm; 18.90 (W) x
5.24 (H) x 14.33 (D) inches
480 (W) x 133 (H) x
364 (D) mm; 18.90 (W) x
5.24 (H) x 14.33 (D) inches
8.6 kg; 18 lb [25W]
8.6 kg; 18 lb [45W]
25W/10W/2.5W [25W]
50W/25W/4.5W [45W]
