CHAPTER 2: Configuring the Thermostat Using the Web Interface
Table 2-9 Network - General Field Descriptions (Continued)
Field
IP Address
Subnet Mask
Default Gateway
DNS Server
MAC Address
Web Server
HTTPS Port
Allow HTTP
HTTP Port
2-34
Beta Draft Confidential
Description
Displays the unique Internet Protocol address either assigned
statically or by DHCP. (See
click Submit after changing this parameter to invoke a software
reset to set the new value.)
A.B.C.D – Four field standard dot notation for IP address
designation.
Displays the IP subnet on which the thermostat IP address is
assigned.
Displays the IP address of the router which acts as a gateway for
the thermostats to communicate to other devices in another
subnet.
Displays the IP address of the Domain Name Server.
Displays a factory assigned value installed in the thermostat
which uniquely identifies the thermostat on the local network for
transmitting and receiving network information.
The system displays the MAC address in the format of
00:19:88:AB:CD:EF for IMT350w and 00:11:49:AB:CD:EF for
IMT350c, where AB:CD:EF is a unique value for each
thermostat.
Enter the IP port number of the Web server within the
thermostat.
xyz – Four digit (max) standard IP port number designation for
HTTP access. The default port number is 443.
Disabled
Enabled
The default is port 80.
Internet Managed Thermostat Configuration Guide, Release 1.0
IP Address Method.) (You must
