CHAPTER 2: Configuring the Thermostat Using the Web Interface
Use
Table 2-8 Advanced - Override Settings Field Descriptions
Field
Hold
Allow Hold
Hold Mode Duration
Away Override Settings
Cool Setting
Heat Setting
Fan Schedule
2-30
Table 2-8 to configure the Override Settings fields.
Internet Managed Thermostat Configuration Guide, Release 1.0
Beta Draft Confidential
Description
Indicates if thermostat temperature setting are held independent
of schedule changes due to Event or Daily Profiles
advancements.
Enabled - Allow the temperature settings to be held for the
duration shown below.
Disabled - Do not allow the temperature settings to be held.
Specifies the time interval in which the thermostat temperature
setting are held independent of schedule changes due to Event or
Daily Profile advancements.
Perm – The Hold period is indefinite and the temperature
setting are "held" until the user removes this condition.
1, 2, 3, 8, 12, 24 Hrs –The amount of time in hours in which
the current temperature setting are "held" and inhibited from
change. The default interval is 3 Hrs.
Note: These durations are observed across Event boundaries.
Displays the cool setpoint to be used while Away is active.
° ° ° °
40 F(4.5 C) to 110 F(43.5 C)
Displays the current temperature programmed for the heating
system.
° ° ° °
40 F(4.5 C) to 110 F(43.5 C)
Specifies the time in minutes of each hour of the Event in which
the fan will be On. The schedule begins on the hour and
advances for the duration specified. Note that within the hour of
each Event but outside the schedule interval, the fan behaves the
same as AUTO mode to ensure proper operation for either a
heating or cooling call to the HVAC system. Select one of the
following options:
Always Off
5 On / 15 Off
10 On / 10 Off
15 On / 5 Off
Always On
