Proliphix IMT350c Configuration Manual page 24

CHAPTER 2: Configuring the Thermostat Using the Web Interface
Table 2-1 Control - HVAC Field Descriptions (Continued)
Field
Cool Setting
Fan Filter Change
Current Schedule
Daily Profile
Event
Heat Setting
Cool Setting
Overrides
Away
Hold
2-4
Beta Draft Confidential
Description
Displays the current temperature programmed for the cooling (A/C) system.
This field is disabled if the HVAC mode is set to Heat or Off. (See
Mode (page 2-5).) This field is not visible if the thermostat is configured to
be a heat-only controlling device. (See
To modify this field, use the drop-down menu to select a Cool Setting.
° ° ° °
40 F(4.5 C) to 110 F(43.5 C)
Displays a reminder that the time interval between HVAC filter changes has
expired. The air filter(s) should be cleaned or replaced. You should change
the filter and then reset this timer. (See
This field is left blank if no filter change is required.
Required! – The HVAC filters require changing or cleaning.
Displays the current active scheduled Profile.
Displays the current active Event.
Morning
Day
Evening
Night
Displays the current Heat temperature setting as set within the current
schedule.
° ° ° °
40 F(4.5 C) to 110 F(43.5 C)
Displays the current Cool temperature setting as set within the current
schedule.
° ° ° °
40 F(4.5 C) to 110 F(43.5 C)
Displays the current state for both the Heat and Cool Setting. To "Away"
the current settings indefinitely or for a prescribed period of time as set on
the Override Settings (page 2-29), use the drop-down menu and choose:
Enabled – Hold mode is enabled.
Off (default) – Away mode is disabled.
Displays the current state for both the Heat and Cool Setting. To "Hold" the
current settings indefinitely or for a prescribed period of time as set on the
Override Settings (page 2-29), use the drop-down menu and choose:
Enabled – Hold mode is enabled.
Off (default) – Hold mode is disabled.
Note: When Occupancy Override is visible, it displays the current state of
an active "Away" button activation.
Internet Managed Thermostat Configuration Guide, Release 1.0
HVAC
Advanced Page (page 2-24).)
Alarms Page (page 2-17).)
Part No. 600-03001-350, Rev. 1
